LG TD-C70070E - Top Plate & Safety Cover Removal; Drawer Assembly Removal

27
DIASSEMBLY INSTRUCTIONS
11
1. Disassemble top plate by unscrewing 2
screws on the rear of the dryer.
DRAWER
TOP PLATE
Note
1. Assemble wires at the HOOK surely when you
reassemble.
2. Disassemble Safety Cover by
unscrewing 2 screws on the top of the
dryer.
3. After pulling drawer assembly out,
unscrew 1 screw.
4. Untie Keeping wire and then
connector(2ea) disassemble from
MAIN PCB
