29
DIASSEMBLY INSTRUCTIONS
11
1. Disassemble grille by releasing 3
hooks.
2. Disassemble cabinet cover by releasing
9 screws.
3. Disassemble cabinet by unscrewing 2
at the top and 3 at the rear
(left and right are the same)
GRILLE
CABINET
COVER
CABINET
