1. Model Information
With advanced inverter technology, is suitable for applications like under floor heating, under floor cooling, and
hot water generation. By Interfacing to various accessories user can customize the range of the application.
In this chapter, general information of is presented to identify the installation procedure. Before beginning
installation, read this chapter carefully and find helpful information on installation.
- Additional Information : serial number is refer to the barcode on the product.
- Max allowable pressure High side / Low side : 4.32 MPa / 2.4 MPa
- Refrigerant : R32
Model number nomenclature
Factory Model Name
1. Model Information
Function
A : General heating heat pump
Product electric power rating
6 : 220-240 V~ 50 Hz
8 : 380-415 V 3N~ 50 Hz
Serial Number
Heating capacity (kW)
Ex) 16 : 16kW class
Model Type
W: DC Inverter Heat Pump
Classification
Air-to-Water Heat Pump for R32
ZH B W 16 6 A 0
M : AWHP Monobloc
H: Air to Water Heat Pump
1 : 50 Hz 220-240 V~
3 : 50 Hz 380-415 V 3N~
H M 16 1 M U3 3
Leaving Water Combination
M : Middle Temperature Leaving Water
U3 : UN3 Chassis
U4 : UN4 Chassis
2 : R410A
3 : R32
Nominal Heating Capacity Indication
Conversion to kW
Ex) “05” : 5 kW, “07” : 7 kW, “09” : 9 kW
“12” : 12 kW, “14” : 14 kW, “16” : 16 kW
Buyer Model Name
