LG THERMA V - User Manual

Other manuals for LG THERMA V

Installation Manual277 pages

Questions and Answers

I
irobertsonSep 8, 2025
What to do if my LG Air Conditioner has exceeded high pressure in DHW mode?
- A
  Andrea GriffinSep 8, 2025
  If your LG Air Conditioner shows an 'Exceeded High Pressure' error in DHW mode, the issue is likely insufficient water flow through the condenser. You can try the following: 1. Check the heating system to ensure the circulation pump is working and that all valves and flaps are correctly opened or closed. 2. Clean the strainer if it is blocked. 3. Fill the system to the correct pressure (min. 1.5–2 bar). 4. Vent the system.
H
Heather HarmonAug 23, 2025
Why is my LG THERMA V heating or cooling not satisfactory?
- D
  Donna BeltranAug 23, 2025
  Unsatisfactory heating or cooling from your LG Heat Pump can stem from several causes. First, verify that the target temperature is set correctly, paying attention to whether the temperature setting is water-based or air-based. Another potential cause is insufficient charged water; in this case, check the pressure gauge and add water until it reads between 2 and 2.5 Bar. Lastly, a low water flow rate could be the culprit. Examine the strainer for excessive particle buildup and clean it if necessary. Also, check if the pressure gauge indicates above 4 Bar, and inspect the water pipe for blockages due to stacked particles or lime.
J
Joseph WeeksAug 25, 2025
How to troubleshoot unsatisfactory heating or cooling in my LG THERMA V?
- J
  johnchambersAug 25, 2025
  If your LG Heat Pump's heating or cooling isn't working well, it could be due to a few reasons. First, make sure the target temperature is set correctly, paying attention to whether it should be water-based or air-based. Also, ensure that the charged water is sufficient by checking the pressure gauge and adding water until it reads 2~2.5 Bar. Finally, check the water flow rate, ensuring the strainer isn't clogged and the pressure gauge isn't above 4 Bar. Also, inspect the water pipe for any obstructions from particles or lime.
J
Justin SmallAug 26, 2025
What to do if my LG THERMA V Heat Pump doesn't start, even with power?
- D
  Dawn ThompsonAug 27, 2025
  If your LG Heat Pump isn't starting even though the power supply is fine, the water inlet temperature might be the issue. If it's above 57 °C, the unit won't start to protect the system. Similarly, in cooling mode, the unit won't operate if the water inlet temperature is below 5 °C. In heating mode, the unit won't operate if the water inlet temperature is below 15 °C. In these cases, wait for the unit to adjust the water inlet temperature. If you're not using a back-up heater, consider increasing the water temperature with an external heat source. If problems persist, it is recommended to contact your dealer.
M
matthew26Aug 27, 2025
What to do if my LG Heat Pump unit doesn't start, even though the remote controller displays information?
- T
  Theresa WheelerAug 28, 2025
  If your LG Heat Pump isn't starting despite the remote controller displaying information, one potential cause is the water inlet temperature. The unit won't operate if the water inlet temperature is above 57°C to protect the system. Alternatively, the water inlet temperature might be too low. If it's below 5°C during cooling, or below 15°C during heating, the unit will not operate. In these cases, allow the unit to warm up the water inlet temperature. If you are not using the back up heater accessory (HA**1M E1), increase the water temperature with the external heat source (heater, boiler).
M
Michael ChandlerSep 22, 2025
What to do if water floods out through the drain hose of my LG THERMA V Heat Pump?
- T
  Trevor MooreSep 22, 2025
  If water is flooding out through the drain hose of your LG Heat Pump, it could be due to two main reasons. The first is that too much water has been charged. To fix this, release water by opening the switch of the safety valve until the pressure gauge indicates between 2 and 2.5 Bar. The other potential cause is a damaged expansion tank. If this is the case, the expansion tank needs to be replaced.
D
Daniel ShawSep 16, 2025
What causes exceeded low pressure in DHW mode on my LG Air Conditioner and how can I fix it?
- N
  ninajenkinsSep 16, 2025
  If your LG Air Conditioner shows an 'Exceeded Low Pressure' error in DHW mode, it's likely due to insufficient air flow through the evaporator. To fix this: 1. Check the operation of the fan on the heat pump. 2. Ensure unobstructed air flow through the evaporator.
E
Elizabeth JosephSep 18, 2025
What does it mean if there is an error on the frequency oscillator on the PLC of my LG Air Conditioner?
- A
  Alexander McbrideSep 18, 2025
  If there is an error on the frequency oscillator on the PLC of your LG Air Conditioner, it indicates that the frequency oscillator on the HP electronics is damaged. You can try the following: 1. Reset the error by pressing and holding the ENTER button for 3 seconds. 2. If the reset doesn't fix the error, contact an authorized service.
K
Kimberly AlexanderSep 7, 2025
What to do if my LG Air Conditioner has exceeded high pressure in space heating mode?
- G
  Gregory MooreSep 7, 2025
  If your LG Air Conditioner displays an 'Exceeded High Pressure' error in space heating mode, it's likely due to insufficient water flow through the condenser. Here are the steps you can take to address this: 1. Check the heating system to ensure the circulation pump is working and that all valves and flaps are correctly opened or closed. 2. Clean the strainer if it is blocked. 3. Fill the system to the correct pressure (min. 1.5–2 bar). 4. Vent the system.
C
christopher03Sep 4, 2025
How to troubleshoot insufficient water flow in LG Air Conditioner's heating system?
- A
  Alexander RangelSep 4, 2025
  If there is insufficient flow of water between your LG Air Conditioner and the heating system, it might be due to insufficient water flow through the condenser or evaporator. To resolve this: 1. Check the heating system to ensure the circulation pump is working and all valves and flaps are correctly opened/closed. 2. Clean the strainer. 3. Fill the system to the correct pressure (1.5–2 bar). 4. Vent the system.
