LG TS-C096EMA0 - Page 16

Models TS-C096YDA0 TS-H096YDA0
Cooling Capacity
2268(2637) 2268(2637)
9,000 9,000
Heating Capacity -
2268(2637)
- 9,000
Power Input Cooling 900 900
Heating - 900
Running Current Cooling 4.4 4.4
Heating --
Starting Current Cooling 6 6
Heating - -
EER 2.52(2.93) 2.52(2.93)
10.00 10.00
COP - 2.9
Power Supply 1Φ,220-240,50 1Φ,220-240,50
Air Circulation Indoor,Max
450 450
Outdoor,Ma
x
1560 1560
Moisture Removal
1.1 1.1
Features Temperature Control
Thermistor Thermistor
Plasma Filter - -
Nano Plasma Filter - -
Deodorizing Filter Optional Optional
CHAOS Wind(Auto Wind)
Yes Yes
Airflow Direction(4-Way:Opti
4-Wa
y
4-Wa
y
Steps, Fan/Cool 3/4 3/4
Airflow Direction Contorl(up
&
Auto Auto
Airflow Direction Contorl(left
&
Manual Manual
Remocon Type Wireless Simple Wireless Simple
Setting Temperature
R
Cool
18 - 30 18 - 30
Heat
- 16 - 30
Temperature Increment
11
Self Diagnosis
Yes Yes
Timer
7h
,
Off 7h
,
Off
Sleep Operation
Yes Yes
Soft Dry Operation
Yes Yes
Restart Delay(minute) 3 3
--
Refrigerant(R22)Charge 430g 630g
Blower Motor Input 29 29
Output 11 11
Motor Input 52 66.6
Motor Outp
u
36 27
--
Power Cord 3*0.75 3*0.75
Connecting Cable 3*0.75 3*0.75
Connecting Tube Liquid Side 6.35(1/4) 6.35(1/4)
(φ. Socket Flare) Gas Side 9.52(3/8) 9.52(3/8)
Length,std 5 5
Drain Hose (O.D , I.D) 21.5,16(0.85,0.63) 21.5,16(0.85,0.63)
Dimension Indoor 161*270*840 161*270*840
Outdoor 520
*575*260 540*770*245
Net Weight Indoor
77
Outdoor 22 33
Unit
kcal/h.(W)
Btu/h.
kcal/h.(W)
Btu/h.
W
W
A
Btu/h.W
W/W
Φ,V,Hz
A
A
A
kcal/h.W(W/W)
g
Special Function
㎥/min(CFM)
㎥/min(CFM)
ℓ/h.(pts/h.)
W
W
W
W
Circuit Breaker A
AWG#:P*㎟
AWG#:P*㎟
mm(in)
mm(in)
m(in)
mm(in)
kg
kg
mm
mm
Product Specifications
Service Manual 16
