Models TS-C126TDA0 TS-H126TDA0
Cooling Capacity
3024(3516) 3024(3516)
12,000 12,000
Heating Capacity
-
3024(3516)
- 12,000
Power Input Cooling 1260 1180
Heating - 1350
Running Current Cooling 6 5.6
Heating - 6.1
Starting Current Cooling 10.7 9
Heating - 8
EER 2.4(2.79) 2.56(2.98)
9.52 10.17
COP - 2.6
Power Supply 1Φ,220-240,50 1Φ,220-240,50
Air Circulation Indoor,Max
450 450
Outdoor,Ma
x
1680 1680
Moisture Removal
1.5 1.5
Features Temperature Control
Thermistor Thermistor
Plasma Filter - -
Nano Plasma Filter - -
Deodorizing Filter Optional Optional
CHAOS Wind(Auto Wind)
Yes Yes
Airflow Direction(4-Way:Opti
4-Wa
y
4-Wa
y
Steps, Fan/Cool 3/4 3/4
Airflow Direction Contorl(up
&
Auto Auto
Airflow Direction Contorl(left
&
Manual Manual
Remocon Type Wireless Simple Wireless Simple
Setting Temperature
R
Cool
18 - 30 18 - 30
Heat
- 16 - 30
Temperature Increment
11
Self Diagnosis
Yes Yes
Timer
7h
,
Off 7h
,
Off
Sleep Operation
Yes Yes
Soft Dry Operation
Yes Yes
Restart Delay(minute) 3 3
--
Refrigerant(R22)Charge 770g 860g
Blower Motor Input 42 42
Output 11 11
Motor Input 109 109
Motor Outp
u
42 42
--
Power Cord 3*1.0 3*1.0
Connecting Cable 3*1.0 3*1.0
Connecting Tube Liquid Side 6.35(1/4) 6.35(1/4)
(φ. Socket Flare) Gas Side 12.7(1/2) 12.7(1/2)
Length,std 5 5
Drain Hose (O.D , I.D) 21.5,16(0.85,0.63) 21.5,16(0.85,0.63)
Dimension Indoor 166*282*895 166*282*895
Outdoor 245*540*770 245*540*770
Net Weight Indoor
88
Outdoor 33 33
kg
kg
mm
mm
mm(in)
mm(in)
m(in)
mm(in)
Circuit Breaker A
AWG#:P*㎟
AWG#:P*㎟
W
W
W
W
g
Special Function
㎥/min(CFM)
㎥/min(CFM)
ℓ/h.(pts/h.)
Btu/h.W
W/W
Φ,V,Hz
A
A
A
kcal/h.W(W/W)
Btu/h.
W
W
A
Unit
kcal/h.(W)
Btu/h.
kcal/h.(W)
Product Specifications
Service Manual 17
