ENGLISH
61
Command Reference List
(Depending on model)
Command1 Command2
Data
(Hexadecimal)
01. Power k a 00 to 01
02. Aspect Ratio k c (See p. 62)
03. Screen Mute k d (See p. 62)
04. Volume
Mute
k e 00 to 01
05. Volume
Control
k f 00 to 64
06. Contrast k g 00 to 64
07. Brightness k h 00 to 64
08. Colour k i 00 to 64
09. Tint k j 00 to 64
10.
Sharpness k k 00 to 32
11.
OSD Select k l 00 to 01
12.
Remote
Control Lock
Mode
k m 00 to 01
13.
Balance k t 00 to 64
14.
Colour
Temperature
x u 00 to 64
15.
Energy Saving j q (See p. 64)
16.
Auto
Configuration
j u 01
17.
Equalizer j v (See p. 64)
18.
Tune
Command
m a (See p. 64)
19.
Channel Skip/
Add
m b 00 to 01
20.
Key m c (See p. 65)
21
Control
Backlight
m g 00 to 64
22.
Input select x b (See p. 65)
• During USB operations such as DivX or EMF, all commands except
Power(ka) and Key(mc) are not executed and treated as NG.
Transmission / Receiving Protocol
(Depending on Model)
Transmission
[Command1][Command2][ ][Set ID][ ][Data][Cr]
[Command1] : First command to control the TV. (j, k, m or x)
[Command2] : Second command to control the TV.
[Set ID] : You can adjust the set ID to choose desired monitor ID number
in option menu. Adjustment range is 1 to 99. When selecting Set ID
‘0’, every connected set is controlled. Set ID is indicated as decimal (1
to 99) on menu and as Hexa decimal (0 x 0 to 0 x 63) on transmission/
receiving protocol.
[Data] : To transmit command data. Transmit ‘FF’ data to read status of
command.
[Cr] : Carriage Return
ASCII code ‘0 x 0D’
[ ] : ASCII code ‘space (0 x 20)’
OK Acknowledgement
[Command2][ ][Set ID][ ][OK][Data][x]
* The set transmits ACK (acknowledgement) based on this format
when receiving normal data. At this time, if the data is data read
mode, it indicates present status data. If the data is data write mode,
it returns the data of the PC computer.
Error Acknowledgement
[Command2][ ][Set ID][ ][NG][Data][x]
* The set transmits ACK (acknowledgement) based on this format
when receiving abnormal data from non-viable functions or commu-
nication errors.
Data 00 : Illegal Code
To Next Page
