8 Dry Contact
Part Description
PDRYCB000 (PCB + Case)
CN-POWER : Connector
CN-CC : Indoor PCB Connector
CN_DRY (L) : DRY CONTROLLER Connector
CN_DRY ( SIG ) : DRY CONTROLLER Connector
CN_DRY (ERROR CHECK) : ERROR Check Display Connector
CN_DRY( OPER STATE): Operation Display Connector
Front Case Rear Case
Metal Case (Front) Metal Case (Rear)
Rubber
PCBA
Side Isolation Sheet
1
2
3
4
5
6
1
2
3
4
5
6
Part Description
