LG VX8560 - Page 100

LG Electronics Inc.
VX8560
Checking Flow
Checking Flow
Check the voltage of the Sub PMIC
+1.2V_DSP_CORE
+2.6V_DSP_SDRAM
+2.6V_DSP_IO
Check DSP Clock at C505
Check the control signal
TP512~520
Replace U608
Replace U511
Replace U510
DSP will operate properly
YES
NO
YES
NO
NO
YES
1
2
3
4.3.2 DSP
4.3.2.1 DSP Trouble
START
XWWVYZ\
100/235
