LG VX8560 - Page 205

LG Electronics Inc.
VX8560
Ref NoPart NamePart Number Spec
.
Maker P/N
C258 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C259 CAP,CERAMIC,CHIP ECCH0006201 4.7 uF,6.3V ,K ,X5R ,TC ,1608 ,R/TP C1608X5R0J475KT
C260 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C261 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C262 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C263 CAP,CERAMIC,CHIP ECCH0006201 4.7 uF,6.3V ,K ,X5R ,TC
,1608 ,R/TP C1608X5R0J475KT
C264 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C265 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C266 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C267 CAP,CERAMIC,CHIP ECCH0006201 4.7 uF,6.3V ,K ,X5R ,TC ,1608 ,R/TP C1608X5R0J475KT
C268 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C269 CAP,CERAMIC,CHIP ECCH0000198 2.2 uF,6.3V ,M ,X5R
,TC ,1005 ,R/TP CL05A225MQ5NNNC
C270 CAP,CERAMIC,CHIP ECCH0009101 0.1 uF,6.3V ,K ,X5R ,TC ,0603 ,R/TP C0603X5R0J104KT
C271 CAP,CERAMIC,CHIP ECCH0000198 2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP CL05A225MQ5NNNC
C272 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C273 CAP,CERAMIC,CHIP ECCH0000198 2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP CL05A225MQ5NNNC
C274 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R
,HD ,1005 ,R/TP GRM36X7R104K10PT
C275 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C276 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C277 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C278 CAP,CERAMIC,CHIP ECCH0000122 47 pF,50V,J,NP0 ,T C,1005,R/TP MCH155A470JK
C279 CAP,CHIP,MAKER ECZH0000816 12 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H120JT
C280 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R
/TP C1005X5R1A105KT
C281 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C282 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C283 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C284 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C285 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C288 CAP,CERAMIC,C
HIP ECCH0009203 33 nF,6.3V ,K ,X5R ,TC ,0603 ,R/TP GRM033R60J333K
C289 CAP,CERAMIC,CHIP ECCH0009203 33 nF,6.3V ,K ,X5R ,TC ,0603 ,R/TP GRM033R60J333K
C290 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP GRM155R60J105KE19D
C303 CAP,CERAMIC,CHIP ECCH0009101 0.1 uF,6.3V ,K ,X5R ,TC ,0603 ,R/TP C0603X5R0J104KT
C305 CAP,CERAMIC,CHIP ECCH0009106 10 nF,16V ,K ,X7R ,TC ,0603 ,R/TP C0603X7R1C103KT
C306 CAP,CERAMIC,CHIP EC
CH0000198 2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP CL05A225MQ5NNNC
C307 CAP,CERAMIC,CHIP ECCH0000198 2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP CL05A225MQ5NNNC
C308 CAP,CHIP,MAKER ECZH0025920 1000 pF,16V ,K ,X7R ,HD ,0603 ,R/TP GRM033R71C102K
C315 CAP,T ANTAL,CHIP ECTH0005704 33 uF,10V ,M ,L_ESR ,2012 ,R/TP , 251M1002336MR3S
C316 CAP,CHIP,MAKER ECZH0025917 47 pF,25V ,J ,NP0 ,TC ,0603 ,R/TP GRM0335C1E470J
C317 CAP,CERAMIC,CHIP ECCH0006501 10000000 pF,6.3V ,K ,X5R ,TC ,2012 ,R/TP , ,1.25 m
mG
RM40X5R106K6.3PT
C319 CAP,CERAMIC,CHIP ECCH0005603 2.2 uF,10V ,K ,X5R ,TC ,1608 ,R/TP GRM39X5R225K10
C320 CAP,CERAMIC,CHIP ECCH0000161 33 nF,16V,K,X7R,HD,1005,R/TP MCH153CN333KK
C400 CAP,CERAMIC,CHIP ECCH0009101 0.1 uF,6.3V ,K ,X5R ,TC ,0603 ,R/TP C0603X5R0J104KT
C4 0 1 VARISTOR SEVY0005101 18 V, ,SMD ,5pF, 1005 ICVL0518050FR
C4 0 2 VARISTOR SEVY0005101 18 V, ,SMD ,5pF, 1005 ICVL0518050FR
C4 0 3 VARISTOR SEVY0005101 18 V, ,SMD ,5pF, 1005 ICVL0518050FR
C404 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C
1005X
5R1A105KT
C4 0 5 VARISTOR SEVY0005101 18 V, ,SMD ,5pF, 1005 ICVL0518050FR
C406 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP GRM155R60J 105KE19D
C4 0 7 VARISTOR SEVY0005101 18 V, ,SMD ,5pF, 1005 ICVL0518050FR
YW\VYZ\
205/235
