LG VX8560 - Page 206

LG Electronics Inc.
VX8560
Ref NoPart NamePart Number Spec
.
Maker P/N
C4 0 8 VARISTOR SEVY0005101 18 V, ,SMD ,5pF, 1005 ICVL0518050FR
C409 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C410 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C411 CAP,CERAMIC,CHIP ECCH0000161 33 nF,16V,K,X7R,HD,1005,R/TP MCH153CN333KK
C412 CAP,CHIP,MAKER ECZH0000826 27 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H270JT
C413 CAP,CHIP,MAKER ECZH0000826 27 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H270JT
C501 CAP,CHIP,MAKER ECZH
0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C502 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C503 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP GRM155R60J 105KE19D
C504 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP GRM155R60J105KE19D
C505 CAP,CERAMIC,CHIP ECCH0000109 8 pF,50V,D,NP0 ,T C,1005,R/TP MCH155A080DK
C506 CAP,CERAMIC,CHIP ECCH0000109 8 pF,50V,D,NP0 ,T C,1005,R
/TP MCH155A080DK
C507 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP MCH153CN103KK
C508 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP GRM155R60J105KE19D
C509 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C510 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP MCH153CN103KK
C511 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,H
D,1005,R/TP MCH153CN103KK
C512 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP MCH153CN103KK
C513 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C514 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C515 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C516 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R
104K10PT
C517 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C518 CAP,CERAMIC,CHIP ECCH0000182 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP GRM36X5R104K10PT
C519 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C520 CAP,CERAMIC,CHIP ECCH0000182 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP GRM36X5R104K10PT
C521 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP MCH153C
N103KK
C522 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP MCH153CN103KK
C523 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP MCH153CN103KK
C524 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP GRM155R60J 105KE19D
C525 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP GRM155R60J 105KE19D
C526 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM
36X7R104K10PT
C527 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP MCH155CN102KK
C601 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C602 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP MCH153CN103KK
C603 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C605 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C606 CAP,CHIP,MAKER EC
ZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C607 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C609 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C610 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP MCH153CN103KK
C611 CAP,CERAMIC,CHIP ECCH0006201 4.7 uF,6.3V ,K ,X5R ,TC ,1608 ,R/TP C1608X5R0J475KT
C612 CAP,CERAMIC,CHIP ECCH0006201 4.7 uF,6.3V ,K ,X5R ,TC ,1608 ,R/TP C1608X5R0J475KT
C613 C
AP,CERAMIC,CHIP ECCH0006201 4.7 uF,6.3V ,K ,X5R ,TC ,1608 ,R/TP C1608X5R0J475KT
C614 CAP,CERAMIC,CHIP ECCH0009103 100 pF,50V ,J ,X7R ,TC ,0603 ,R/TP C0603C0G1H101JT
C615 CAP,CERAMIC,CHIP ECCH0009110 22 nF,6.3V ,K ,X7R ,TC ,0603 ,R/TP C0603X7R0J223KT
C616 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP GRM155R60J 105KE19D
C617 CAP,CERAMIC,CHIP ECCH0000161 33 nF,16V,K,X7R,HD,1005,R/TP MCH153CN333KK
C618 CAP,C
ERAMIC,CHIP ECCH0000161 33 nF,16V,K,X7R,HD,1005,R/TP MCH153CN333KK
YW]VYZ\
206/235
