LG VX8560 - Page 208

LG Electronics Inc.
VX8560
Ref NoPart NamePart Number Spec
.
Maker P/N
C717 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C718 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C719 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C720 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C721 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C722 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C724 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R
,TC ,1005 ,R/TP C1005X5R1A105KT
C726 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C7 2 8 VARISTOR SEVY0005101 18 V, ,SMD ,5pF, 1005 ICVL0518050FR
C729 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C730 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C731 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C732 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C733 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G
1H101JT
C734 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C735 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C736 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C737 CAP,CERAMIC,CHIP ECCH0009103 100 pF,50V ,J ,X7R ,TC ,0603 ,R/TP C0603C0G1H101JT
C738 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C739 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C740 CAP,CH
IP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
C745 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP GRM36X7R104K10PT
C746 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
C748 CAP,CERAMIC,CHIP ECCH0004904 1 uF,6.3V ,K ,X5R ,TC ,1005 ,R/TP GRM155R60J 105KE19D
C749 CAP,CERAMIC,CHIP ECCH0000182 0.1 uF,10V ,K ,X5R ,HD ,1005 ,R/TP GRM36X5R104K10PT
C750 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD
,1005,R/TP MCH155CN102KK
C751 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP MCH155CN102KK
C752 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP MCH155CN102KK
C753 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP MCH155CN102KK
C754 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP MCH155CN102KK
C755 CAP,CERAMIC
,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP MCH155CN102KK
C756 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H330JT
C757 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP MCH155CN102KK
C758 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP C1005X5R1A105KT
CON300 CONNECTOR,ETC ENZY0021401 4 ,19 mm,BOTTOM , , HSBC-4PT25-19
CON401 CONN,SOCKET ENSY0014701 8 PIN,ETC , ,1.1 mm
,H=1.95, Rev er se 49225-0821
CON402 CONNECTOR,I/O ENRY0007201 5 ,0.65 mm,ANGLE , , ,; , ,0.64MM ,ANGLE AXJ53314
CON601 CONN,JACK/PL UG,EARPHONEENJE0006701 4 ,5 PIN, ,; ,4P ,4P ,ANGLE ,[empty] , ,BLACK , 7620-3.5G-DB1 -A
CON602 CONN,RECEPTACLE ENEY0003801 2 PIN, , , 24-8000-002-000-829
CON703 CONNECTOR,BOARD TO BOARDENBY0019901 80 PIN,0.4 mm,ETC , ,H=1.5, Socket AXK780147G
D300 DIODE,T VS EDTY0008601 SOD-323 ,6 V,400 W,R/TP ,PB-FREE PSD05- LF
D400 DIOD
E,T VS EDTY0009601 SLP1006P2 ,5 V,100 W,R/TP ,1.0x0.6x0.5t , Rclamp0521P.TCT
D401 DIODE,T VS EDTY0009601 SLP1006P2 ,5 V,100 W,R/TP ,1.0x0.6x0.5t Rclamp0521P.TCT
D402 DIODE,SWITCHINGEDSY0017701 SOD-123 ,40 V,1 A,R/TP , ,,2P ,1 SDB10 4 0
D403 DIODE,T VS EDTY0009601 SLP1006P2 ,5 V,100 W,R/TP ,1.0x0.6x0.5t Rclamp0521P.TCT
D404 DIODE,T VS EDTY0009601 SLP1006P2 ,5 V,100 W,R/TP ,1.0x0.6x0.5t Rclamp0521P.TCT
D405 DIODE,T VS EDTY0009401 VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100m
W
RSB6 .8 CST2 R
D406 DIODE,T VS EDTY0009401 VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100m
W
RSB6 .8 CST2 R
D407 DIODE,T VS EDTY0009401 VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100m
W
RSB6 .8 CST2 R
YW_VYZ\
208/235
