LG VX8560 - Page 209

LG Electronics Inc.
VX8560
Ref N
o
Part Name Part Number Spec. Maker P/N
D6 02 DIODE ,S WI TCHI NG EDSY0010001 UMD2 ,30 V,2 A,R/TP ,SCHOTTKY BARRIER DIODE RB551V-30TE-17
DP 1 0 0 MODUL E,E T C S MZY0017501 S-Quintplexer, QSC pin to pin, CDMA+USPCS+SGPS, ACFM-7103
F102 TR, FET, P-CHANNEL EQFP0009301
MLF-4 ,0 W,0 V,1.2 A,R/TP ,Load Switch ,; ,P-CHANNEL
,MOSFET ,; ,; ,; ,; ,; ,MELF ,R/TP ,4P MI C94071
F103 FI LTER,CERAMIC SFCY0000901 2450 MHz,2.00*1.25*0.95 ,SMD ,Bluetooth Band Pass LFB212G45SG8A166
F104 FI LTER,SAW, DUAL SFSB0001202
881.5 MHz,25 MHz,2.4 dB,35 dB,1960 MHz,60 MHz,3.2
dB,17 dB,2.0*1.6*0.5 ,SMD
,869M~894M, 1930M~1990M,1 0 p ,B,1 0 0 ,10 0 _ 1 5 ,DCN+U
S
FAR-G6KE-1G9600- Y4RD
F105 FI LTER,SAW, DUAL SFSB0001601
836.5 MHz,25 MHz,2.2 dB,40 dB,1880 MHz,58.75 MHz,4
dB,30 dB,2.0*1.6*0.68 ,SMD
,824M~849M, 1850. 625M~1909.375M,1 0 p ,B ,5 0 ,5 0 ,DCN+ B 931 4
F301 FI LTER,EMI/POWER SFEY0015301 SMD ,Pb-free_Bais ,; ,Filter,LCR NFM18PC104R1C3
F400 I C EUSY0338301 uMLP ,10 PIN,R/TP ,High Speed USB Siwitch 2.0 3.7pF FSUSB103UMX
F701 FI LTER,EMI/POWER SFEY0010501 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (100Ohm,15pF), ICVE10184E150R101FR
F702 FI LTER,EMI/POWER SFEY0010501 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (100Ohm,15pF), ICVE10184E150R101FR
F703 FI LTER,EMI/POWER SFEY0010501 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (100Ohm,15pF), ICVE10184E150R101FR
F704 FI LTER,EMI/POWER SFEY0010501 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (100Ohm,15pF), ICVE10184E150R101FR
F705 FI LTER,EMI/POWER SFEY0010501 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (100Ohm,15pF), ICVE10184E150R101FR
F706 FI LTER,EMI/POWER SFEY0011701 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (10 Ohm,7.5pF) ICVE10184E070R100FR
F707 FI LTER,EMI/POWER SFEY0011701 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (10 Ohm,7.5pF) ICVE10184E070R100FR
F708 IC EUSY0355701 PLP1010-4 ,4 PIN,R/TP ,150mA 2.8V Single LDO ,; RP103K281D-TR-F
F709 IC EUSY0353701 PLP1010-4 ,4 PIN,R/TP ,1x1 LDO, 2.6V , 150mA ,; RP104K261D
L100 INDUCTOR,CHIP ELCH0001417 33 nH,J ,1005 ,R/TP ,PBFREE LL1005-FHL33NJ
L101 CAP, CERAMIC,CHIP ECCH0000701 1.2 pF,50V ,C ,NP0 , TC ,1005 ,R/TP C1005C0G1H1R2CT
L103 INDUCTOR,CHIP ELCH0001420 3.9 nH,S ,1005 ,R/TP ,PBFREE LL1005-FHL3N9S
L107 INDUCTOR,CHIP ELCH0004718 5.6 nH,S ,1005 ,R/TP , 1005GC2T5N6S00
L109 INDUCTOR,CHIP ELCH0001416 2.7 nH,S ,1005 ,R/TP ,PBFREE LL1005-FHL2N7S
L110 INDUCTOR,CHIP ELCH0001002 5.6 nH,J ,1005 ,R/TP ,chip inductor PBFREE ELJRF5N6JFB
L113 INDUCTOR,CHIP ELCH0001409 10 nH,J ,1005 ,R/TP ,PBFREE LL1005-FHL10NJ
L114 INDUCTOR,CHIP ELCH0001420 3.9 nH,S ,1005 ,R/TP ,PBFREE LL1005-FHL3N9S
L116 INDUCTOR,CHIP ELCH0001408 6.8 nH,J ,1005 ,R/TP ,Pb Free LL1005-FHL6N8J
L117 INDUCTOR,CHIP ELCH0001422 4.7 nH,J ,1005 ,R/TP ,PBFREE LL1005-FHL4N7J
L121 INDUCTOR,CHIP ELCH0001417 33 nH,J ,1005 ,R/TP ,PBFREE LL1005-FHL33NJ
L122 INDUCTOR,CHIP ELCH0001417 33 nH,J ,1005 ,R/TP ,PBFREE LL1005-FHL33NJ
L123 CAP, CHI P, MAKER ECZH0000806 5 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP C1005C0G1H050CT
L124 CAP, CERAMIC,CHIP ECCH0000183 1.8 pF,50V ,C ,NP0 , TC ,1005 ,R/TP GRM3 6 C0 G1 R8 C5 0 PT
L127 FILTER,BEAD,CHIP SFBH0008101 600 ohm,1005 , BLM15AG601SN1
L128 INDUCTOR,CHIP ELCH0001406 4.7 nH,S ,1005 ,R/TP ,PBFREE LL1005-FHL4N7S
L129 INDUCTOR,CHIP ELCH0001406 4.7 nH,S ,1005 ,R/TP ,PBFREE LL1005-FHL4N7S
L130 INDUCTOR,CHIP ELCH0001403 1 nH,S ,1005 ,R/TP ,PBFREE LL1005-FHL1N0S
L131 INDUCTOR,CHIP ELCH0001403 1 nH,S ,1005 ,R/TP ,PBFREE LL1005-FHL1N0S
L134 CAP, CERAMIC,CHIP ECCH0000180 3.3 pF,50V ,C ,NP0 , TC ,1005 ,R/TP GRM3 6 C0 G3 R3 C5 0 PT
L136 CAP, CHI P, MAKER ECZH0000802 1 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP C1005C0G1H010CT
L 2 0 0 INDUCT OR,SMD,P OWER ELCP0008005
4.7 uH,M ,2.5X2.0X1.0 ,R/TP ,MLCI ,; ,; ,20% ,; ,; ,; ,; ,;
,SHIELD ,2.5X2X1MM ,[empty] ,R/TP ,Inductor,Wi r e CPI 2520LZ4R7ME
L 2 0 1 INDUCT OR,SMD,P OWER ELCP0008005
4.7 uH,M ,2.5X2.0X1.0 ,R/TP ,M
LCI ,; ,; ,20% ,; ,; ,; ,; ,;
,SHIELD ,2.5X2X1M
M ,[empty] ,R/TP ,Inductor,Wir e CPI 2520LZ4R7ME
L604 INDUCTOR,CHIP ELCH0004915 120 nH,J ,1608 ,R/TP , 1608GC2TR12J00
L 6 0 6 INDUCT OR,SMD,P OWER ELCP0008002 2.2 uH,M ,2.5*2.0*1.0 ,R/TP , MI P2520D2R2M
L607 INDUCTOR,CHIP ELCH0004203 68 nH,J ,1608 ,R/TP , LL1608-FS68NJ
L608 INDUCTOR,CHIP ELCH0004203 68 nH,J ,1608 ,R/TP , LL1608-FS68NJ
L700 INDUCTOR,CHIP ELCH0001425 82 nH,J ,1005 ,R/TP ,PBFREE LL1005-FHL82NJ
L701 INDUCTOR,CHIP ELCH0001425 82 nH,J ,1005 ,R/TP ,PBFREE LL1005-FHL82NJ
L702 INDUCTOR,CHIP ELCH0001425 82 nH,J ,1005 ,R/TP ,PBFREE LL1005-FHL82NJ
L ED6 0 1 DIODE,L ED,CHIP E DL H0 0 1 3 7 0 1 WHITE ,ETC ,R/TP ,SIDEVIEW ,; ,[empty] ,2.9~3.75 LEWWS44PA
L ED6 0 2 DIODE,L ED,CHIP E DL H0 0 1 3 7 0 1 WHITE ,ETC ,R/TP ,SIDEVIEW ,; ,[empty] ,2.9~3.75 LEWWS44PA
YW`VYZ\
209/235
