LG VX8560 - Page 210

LG Electronics Inc.
VX8560
Ref NoPart NamePart Number Spec
.
Maker P/N
M601 MICROPHONESUMY0010604
UNIT ,-38 dB,4.72*3.76 ,1.25T Bottom Silicon type ,; , ,
,UNI ,1.5V , ,SMD SPM0204LE5- QB
Q300 TR,FET,P-CHANNEL EQFP0008601 DFN8 ,1.3 W,-20 V,-3.9 A,R/TP ,Intergrated power NUS5530MN
R104 RES,CHIP,MAKER ERHZ0000291 49.9 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF49R9
R105 RES,CHIP,MAKER ERHZ0000490 51 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 510
R106 RES,CHIP,MAKER ERHZ0000236 2000 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF2001
R107 RES,CHIP ERHY0009503 100 ohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ101
R
109 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ103
R110 RES,CHIP,MAKER ERHZ0000420 150 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 151
R111 RES,CHIP,MAKER ERHZ0000473 39 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 390
R112 RES,CHIP,MAKER ERHZ0000420 150 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 151
R113 RES,CHIP,MAKER ERHZ0000410 12 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 120
R114 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP C1005C0G1H101JT
R116 RES,CHIP ERHY0003201 1000 ohm,1/16W ,F ,1005 ,R/TP MCR
01MZSF1001
R119 RES,CHIP,MAKER ERHZ0000222 150 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF1503
R121 RES,CHIP ERHY0009503 100 ohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ101
R122 RES,CHIP ERHY0009503 100 ohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ101
R123 RES,CHIP ERHY0009503 100 ohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ101
R124 RES,CHIP ERHY0009503 100 ohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ101
R128 I NDUCTOR,CHIP ELCH0005001 2.2 nH,S ,1005 ,R/TP , HK10052N2S
R200 RES,CHIP,MAKER ERHZ0000298 560 ohm
,1/16W ,F ,1005 ,R/TP MCR01MZSF5600
R201 RES,CHIP,MAKER ERHZ0000293 510 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF5100
R215 RES,CHIP,MAKER ERHZ0000488 4.7 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ4R7
R216 RES,CHIP,MAKER ERHZ0000294 5100 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF5101
R217 RES,CHIP,MAKER ERHZ0000206 10 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF10R0
R218 RES,CHIP,MAKER ERHZ0000294 5100 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF5101
R219 RES,CHIP,MAKER ERHZ0000212 12 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF1202
R220 R
ES,CHIP,MAKER ERHZ0000456 2.2 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ2R2
R221 RES,CHIP,MAKER ERHZ0004201 121000 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF1213
R224 RES,CHIP ERHY0009526 4.7 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ472
R231 RES,CHIP,MAKER ERHZ0000295 51 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF5102
R232 RES,CHIP ERHY0009536 100 Kohm,1/20W(0.05W) ,F ,0603 ,R/TP MCR006YZPF1003
R233 THERMISTOR SETY0001401 NTC ,68 Kohm,SMD ,NCP1 8WD683E03RB
R234 RES,CHIP,MAKER ERHZ0000206 10 ohm,1/16W ,F ,1005 ,R/TP MC
R01MZSF10R0
R235 RES,CHIP,MAKER ERHZ0000206 10 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF10R0
R236 RES,CHIP,MAKER ERHZ0000315 75 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF7502
R237 RES,CHIP,MAKER ERHZ0000222 150 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF1503
R238 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ222
R302 RES,CHIP ERHY0009505 10 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ103
R305 RES,CHIP,MAKER ERHZ0003901 0.1 ohm,1/4W ,F ,2012 ,R/TP ,; ,0.1 ,1% ,1/4W ,2012 MCR10EZHFLR100
R3 0 7 VARISTO
R SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R3 0 8 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R309 RES,CHIP,MAKER ERHZ0000288 470 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF4703
R310 RES,CHIP,MAKER ERHZ0000318 80.6 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF8062
R311 RES,CHIP,MAKER ERHZ0000286 4700 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF4701
R312 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ513
R400 RES,CHIP ERHY0009503 100 ohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ101
R401 RES,CHIP,MAKER ERHZ0000402 10 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 100
R403 RES,CHIP,MAKER ERHZ0000498 56 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ563
R404 RES,CHIP,MAKER ERHZ0000238 200 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF2003
YXWVYZ\
210/235
