LG VX8560 - Page 211

LG Electronics Inc.
VX8560
Ref NoPart NamePart Number Spec
.
Maker P/N
R4 0 5 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R4 0 9 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R501 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ473
R502 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R503 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ473
R504 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R505 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R506 RES,CHIP,MAKER ERHZ0000507 68 Kohm,1/16W ,J ,1005 ,R
/TP MCR01MZSJ683
R507 RES,CHIP,MAKER ERHZ0000507 68 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 683
R508 RES,CHIP,MAKER ERHZ0000507 68 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 683
R509 RES,CHIP,MAKER ERHZ0000507 68 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 683
R510 RES,CHIP ERHY0009526 4.7 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ472
R511 RES,CHIP ERHY0009526 4.7 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ472
R513 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 103
R514 RES,CHIP,MAKER ER
HZ0000287 47 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF4702
R515 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R516 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R519 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R520 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R521 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 104
R522 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R523 R
ES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ473
R524 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R525 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R526 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R527 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 473
R528 RES,CHIP ERHY0018901 44.2 ohm,1/16W ,F ,1005 ,R/TP ,; ,44.2 ,1% ,1/16W MCR01MZPF44R2
R532 RES,CHIP,MAKER ERHZ0000485 4700 ohm,1/16W ,J ,1005 ,R/TP MC
R01MZSJ 472
R533 RES,CHIP ERHY0009526 4.7 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ472
R534 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 103
R536 RES,CHIP ERHY0009526 4.7 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ472
R537 RES,CHIP ERHY0009526 4.7 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ472
R538 RES,CHIP ERHY0009526 4.7 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ472
R539 RES,CHIP ERHY0009526 4.7 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ472
R540 RES,CHIP,MAKER ERHZ0000457 30 ohm
,1/16W ,J ,1005 ,R/TP MCR01MZSJ 300
R605 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 103
R606 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 103
R607 RES,CHIP ERHY0003201 1000 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF1001
R608 RES,CHIP ERHY0003201 1000 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF1001
R6 1 0 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R6 1 1 VARISTOR SEVY0007301 5 V,<0.5pF ,SMD ,ULCE0505C015FR
R6 1 2 VARISTOR SEVY0007301 5 V,<0.5pF ,SMD ,ULCE0505C015FR
R6 1 3 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R6 2 0 VARISTOR SEVY0003601 5.6 V, ,SM
D ,100pF, 1005 ICVL0505101V150FR
R623 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ103
R626 RES,CHIP,MAKER ERHZ0000291 49.9 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF49R9
R627 RES,CHIP,MAKER ERHZ0000291 49.9 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF49R9
R6 3 5 VARISTOR SEVY0005202 5.5 V,+-30 ,SMD ,1005, 100 pF, Pb free EVLC5S02100
R637 RES,CHIP ERHY0009526 4.7 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ472
