LG VX8560 - Page 212

LG Electronics Inc.
VX8560
Ref NoPart NamePart Number Spec
.
Maker P/N
R638 RES,CHIP ERHY0009526 4.7 Kohm,1/20W(0.05W) ,J ,0603 ,R/TP MCR006MZPJ472
R640 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ101
R641 DIODE,T VS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE PRSB6.8 C
R644 RES,CHIP,MAKER ERHZ0000529 1.5 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 152
R645 RES,CHIP,MAKER ERHZ0000529 1.5 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 152
R646 RES,CHIP,MAKER ERHZ0000422 15 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ153
R647 RES,CHIP,MAKER ERHZ0000437 2 Kohm,1/16W ,J ,1005 ,R/TP MC
R01MZSJ202
R648 DIODE,T VS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE PRSB6.8 C
R650 RES,CHIP,MAKER ERHZ0000279 39 Kohm,1/16W ,F ,1005 ,R/TP MCR01MZSF3902
R651 RES,CHIP,MAKER ERHZ0000537 680000 ohm,1/16W ,F ,1005 ,R/TP RC1005F684CS
R6 5 4 VARISTOR SEVY0005202 5.5 V,+-30 ,SMD ,1005, 100 pF, Pb free EVLC5S02100
R6 5 5 VARISTOR SEVY0005202 5.5 V,+-30 ,SMD ,1005, 100 pF, Pb free EVLC5S02100
R6 5 6 VARISTOR SEVY0005202 5.5 V,+-30 ,SMD ,1005, 100 pF, Pb free EVLC5S02100
R6 5 7 VARISTOR SEVY0005202 5.5 V,+-30 ,SMD ,1005, 100 pF, Pb free EVLC5S02100
R705 RES,CHIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R706 RES,CHIP ERHY0009541 470 ohm,1/20W(0.05W) ,F ,0603 ,R/TP MCR
006YZPF4700
R7 0 7 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R708 RES,CHIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R709 RES,CHIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R710 RES,CHIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R711 RES,CHIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R712 RES,CHIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R713 RES,CHIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R714 RES,C
HIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R715 RES,CHIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R716 RES,CHIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R717 RES,CHIP,MAKER ERHZ0000484 470 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ471
R719 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 000
R722 RES,CHIP,MAKER ERHZ0000348 12 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF12R0
R723 RES,CHIP,MAKER ERHZ0000348 12 ohm,1/16W ,F ,1005 ,R/TP MCR
01MZSF12R0
R724 RES,CHIP,MAKER ERHZ0000348 12 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF12R0
R725 RES,CHIP,MAKER ERHZ0000348 12 ohm,1/16W ,F ,1005 ,R/TP MCR01MZSF12R0
R7 2 6 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R7 2 7 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R7 2 8 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R7 2 9 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R7 3 0 VARISTOR SEVY0005101 18 V, ,SMD ,5pF, 1005 ICVL0518050FR
R7 3 1 VARISTOR SEVY0005101 18 V, ,SMD ,5pF, 1005 ICVL0518050FR
R7 3 2 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R7 3 3 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R7 3 4 VARISTOR SEVY0003601 5.6 V, ,SMD ,100pF, 1005 ICVL0505101V150FR
R7 3 6 VARISTO
R SEVY0007301 5 V,<0.5pF ,SMD ,ULCE0505C015FR
R7 3 7 VARISTOR SEVY0007301 5 V,<0.5pF ,SMD ,ULCE0505C015FR
R7 3 8 VARISTOR SEVY0007301 5 V,<0.5pF ,SMD ,ULCE0505C015FR
R7 3 9 VARISTOR SEVY0007301 5 V,<0.5pF ,SMD ,ULCE0505C015FR
R740 RES,CHIP,MAKER ERHZ0000529 1.5 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 152
R741 RES,CHIP,MAKER ERHZ0000529 1.5 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ 152
U100 CONN,RF SWITCHENWY0003301 ,SMD ,0.4 dB, KMS-5 0 7
U102 COUPL ER,RF DIRECTIONAL SCDY0003901
19.8 dB,0.28 dB,33 dB,1.0*0.5*0.4 ,SMD ,Pb-
fr ee_Coupler _DCN Tx ,; ,[empty] ,836.5MH
z ,25MHzLDC15836M20Q-360
YXYVYZ\
212/235
