LG Electronics Inc.
VX8560
Ref N
o
Part Name Part Number Spec. Maker P/N
U103 COUPLER,RF DIRECTIONAL SCDY0003801
20.5 dB,0.25 dB,34 dB,1.0*0.5*0.4 ,SMD ,Pb-
free_Coupler_USPCS Tx ,; ,[empty] ,1880MHz ,60MHz
,SMD ,R/TP LDC151G8820Q-359
U1 0 5 MODUL E,E T C S MZY0016501 LNA Module(GPS LNA+B/P Filter) ,: ,RF Module ALM-1412
U106 PAM SMPY0017301 dBm, %, A, dBc, dB,4x5 ,SMD , ,; , , , , , , , ,R/TP ,R/TP , ACPM-7353
U109 IC EUSY0350101 WFBGA ,65 PIN,R/TP ,Bluetooth V2.1 5x5x0.8 ,; BCM2046SB1
U200 I C EUSY0348601
CSP ,424 PIN,R/TP ,EVDO BB, RF, PM Onechi p
Baseband ,; ,IC,Digital Baseband Processor QSC6075
U201 X- TAL EXXY0024301
32.768 KHz,20 PPM,12.5 pF,70 Kohm,SMD ,3.2*1.5*0.9
,-40'C ~ +85'C, C0 1.05pF, C1 fF ,; ,32.768 ,20PPM ,12.5 CM315(12. 5PF)
U300 I C EUSY0347503
FBGA ,149 PIN,ETC ,FULLY 1.8V 2G(LB/128Mx16)
NAND+ 1G(DDR/1 6 Mx4x16) SDRAM ,; ,IC,MCP H8 BCS0SI0 MAP-56M
U400 IC EUSY0333701 TLLGA ,8 PIN,R/TP ,OVP NUS3065MUTAG
U506 IC EUSY0140902 SSOP ,5 PIN,R/TP ,Inverter(2x2.1) TC7SZ04FU
U507 IC EUSY0354501 FBGA ,153 PIN,ETC ,1GB eMMC / 11.5x13 / moviNAND KMAFE0000A
U508 I C EUSY0306203 Micropak ,6 PIN,R/TP ,1x1.45 ,; ,IC,TTL NC7SZ373L6X
U509 I C EUSY0306203 Micropak ,6 PIN,R/TP ,1x1.45 ,; ,IC,TTL NC7SZ373L6X
U510 IC EUSY0353201 BGA ,160 PIN,R/TP ,MP3,H.264_QVGA,3M,USB2.0 ,; TCC8322
U511 X- TAL EXXY0017801
12 MHz,50 PPM,8 pF,80 ohm,SMD ,3.2*2.5*0.75 ,20ppm
at 25'C, 30ppm at -30'C ~ +85'C DSX321G(12MHZ, 8PF)
U601 IC EUSY0352801 QFN ,20 PIN,R/TP ,FM Transmitter, SMD, 3*3*0.55, Pb SI4710-B30-GMR
U602 IC EUSY0334901 WLCSP ,9 PIN,R/TP ,monaural 2.1W non-clip Digital YDA145-PZE2
U603 IC EUSY0250501 SC70 ,5 PIN,R/TP ,Comparator, pin compatible to NCS2200SQ2T2G
U604 IC EUSY0334901 WLCSP ,9 PIN,R/TP ,monaural 2.1W non-clip Digital YDA145-PZE2
U605 IC EUSY0354701 QFN ,40 PIN,R/TP ,5x5 ,; ,IC,Audio Codec WM8900
U606 I C EUSY0186502 Micropak ,6 PIN,R/TP ,Single SPDT Analog Switch, Pb FSA4157L6X
U607 IC EUSY0313401 QFN ,4 PIN,R/TP ,1.8X1.2X0.5 size wide input voltage EM-0781-T5
U608 I C EUSY0227205 Micro SMC ,20 PIN,R/TP ,MM PM ,; ,IC,DC,DC LP8720TLX
U609 IC EUSY0254201 DFN ,12 PIN,R/TP ,Dual SPDT Analog Switch(Pb Free) NLAS3158MNR2 G
U610 I C EUSY0253802
QFN ,28 PIN,R/TP ,QFN-28, 28PIN, 2LDOs, ALC,
6PORT Charge Pump ,; ,IC,Sub PMIC SM8158BB-G- EL
U700 IC EUSY0331801 Photo sensor IC, 6 PIN, Vcc 1.8 to 5.5V ,6 PIN,R/TP APDS-9005-020
X100 X-TAL EXXY0018403
26 MHz,10 PPM, pF, ohm,SMD ,3.2*2.5*0.7 ,temporary
spec, W-191-451 ,; ,26 ,10PPM
, , , ,SMD ,R/TP NX3225SA(EXS00A-CS00275)
X101 VCTCXO EXSK0005703
19.2 MHz,1.5 PPM,40 pF,SMD ,3.2*2.5*0.9 , ,; , ,1.5PPM
,2.8V ,3.2 ,2.5 ,0.9 , ,SM
D ,P/TP DSA321SCE(19.2M)
YXZVYZ\
213/235
