LG VX8560 - Page 214

LG Electronics Inc.
VX8560
5-2.FPCB Part List
5-2.FPCB Part List
Ref N
o
Part NamePart Number Spec
.
Maker P/
N
SACC00 PCB ASSY, FLEXIBLE,SMT BOTTOM SACC0043401
C101 CAP,CERAMIC,CHIP ECCH0000198 2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP CL05A225MQ5NNNC
CON104 CONNECTOR,BOARD TO BOARDENBY0019801 80 PIN,0.4 mm,ETC , ,H=1.5, Header AXK880145WG
CON105 CONNECTOR,BOARD TO BOARDENBY0046001 44 PIN,0.4 mm,STRAIGHT , , ,; , ,0.40MM ,STRAIGHT ,MALE ,SMD ,AXT544124
R102 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W
,J ,1005 ,R/TP MCR01MZSJ000
R104 RES,CHIP,MAKER ERHZ0000507 68 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ6 83
R125 RES,CHIP,MAKER ERHZ0000507 68 Kohm,1/16W ,J ,1005 ,R/TP MCR01MZSJ6 83
SACD00 PCB ASSY,FLEXIBLE,SMT TOP SACD0055301
C102 CAP,CERAMIC,CHIP ECCH0000198 2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP CL05A225MQ5NNNC
CON101 CONNECTOR,BOARD TO BOARDENBY0018601 10 PIN,.4 mm,STRAIGHT , ,H=0.9, SOCKET AXK7L10227G
CON103 CO
NNECTOR,BOARD TO BOARDENBY0020401 24 PIN,0.4 mm,ETC , ,H=0.9, Socket AXK7L24227G
CON106 CONNECTOR,FFC/F PC ENQY0008602 6 PIN,0.5 mm,ETC ,AU ,H:1.2MM 04- 6298-006- 000-883
D101 DIODE,T VS EDTY0009401 VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100mW , ,2P ,1 RSB6 .8CST 2 R
D102 DIODE,T VS EDTY0009401 VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100mW ,2P ,1 RSB6 .8 CST2 R
SPCY00 PCB,F L EXIBL E SPCY0133301 POLYI ,.5 mm,MULTI-7[BUILDUP] , ,; , , , , , , , , , SPCY0133301
YX[VYZ\
214/235
