LG W1943C User Manual

A10
On Screen Display (OSD) Control Adjustment
Screen Adjustment
Making adjustments to the image size, position and operating parameters of
the display is quick and easy with the On Screen Display Control system.
A short example is given below to familiarize you with the use of the controls.
The following section is an outline of the available adjustments and selections
you can make using the OSD.
To make adjustments in the On Screen Display, follow these steps:
Press the MENU Button, then the main menu of the OSD appears.
To access a control, use the or Buttons. When the icon you want
becomes highlighted, press the AUTO/SET Button.
Use the / Buttonsto adjust the image to the desired level. Use the
AUTO/SET Button to select other sub-menu items.
Push the MENU Buttononce to return to the main menu to select another
function. Push the MENU Buttontwice to exit from the OSD.
NOTE
Allow the display to stabilize for at least 30 minutes before making image adjustments.

LG W1943C Specifications

General

Pixel pitch	0.300 x 0.300 mm
Aspect ratio	-
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Vertical scan range	56 - 75 Hz
Viewing angle, vertical	50 °
Contrast ratio (dynamic)	50000:1
Viewing angle, horizontal	90 °
Display brightness (typical)	200 cd/m²
DVI-I ports quantity	0
Power consumption (standby)	1 W
Power consumption (typical)	21 W
Product color	Black
LED indicators	Stand-by
Panel mounting interface	75 x 75 mm
Package weight	4300 g

Weight and Dimensions

Depth (without stand)	183 mm
Width (without stand)	448.9 mm
Height (without stand)	361.1 mm
Weight (without stand)	2900 g
