LG WD-1036(0~9)SD - Dispenser Assembly

25
DRAWER
Disassemble the top plate assembly.
Pull out the drawer to arrow direction.
Unscrew 2 screws.
The hose clamps and the hose are disassembled.
The ventilation bellows and the water inlet bellows are
disassembled on the tub.
Option
DISPENSER ASSEMBLY
DISPENSER ASSEMBLY
PUSH
