9
nstallation
I
"
Installation of drain hose
max. 100 cm
min. 60 cm
ca. 105 cm
ca. 145 cm
ca. 100 cm
max. 100cm
min. 60cm
Hose
Retainer
Laundry tub
Tie
strap
max. 100cm
min. 60cm
max. 100 cm
ca. 105 cm
ca. 145 cm
ca. 100 cm
min. 60 cm
The drain hose should not be placed
higher than 100 cm above the floor.
Proper securing the drain hose will
protect the floor from damage due to
water leakage.
When the drain hose is too long, please
dont fill into the washer. This will cause
abnormal noise.
When installing the drain hose sink,
secure it tightly with a string.
Proper securing the drain hose will protect
the floor from damage due to water
leakage.
When installing the drain hose sink,
secure it tightly with a string.
Proper securing the drain hose will protect
the floor from damage due to water
leakage.
