SPIN TROUBLE
Normal.
Reconnect or repair it.
Replace the motor
assembly.
(4681FR1194A) or
(4681FR1194B)
Check the sensor (Pressure) or hose (Sensor).
If the problem is on the sensor or the hose,
replace the sensor or the hose.
Press Power button with both Temp. and Option
buttons pressed after power off. Press Start/Pause
button 2 times. Does the drum rotate at low spin
speed?
Is it disconnected or badly contacted?
Red : 3pin ( ), Natural : 4pin ( ), White : 2pin( ),
Natural : 3pin(
)
Check the motor connector, Is the resistance between
the terminal in figure the same as below?
Resistance between terminals
~ : 0.5~1.0
~ : 1.5~2.5
Be sure to unplug the machine before measuring.
MOTOR TERMINAL
Replace the PWB assembly.
To Next Page
