LG WT-R10(~3)3(7)1(3,5)TP(H) User Manual

5
2-1. HOW TO LEVEL THE WASHING MACHINE
Check the level of the washing machine using a spirit level on the side of the washer cabinet
You can check the level also by visually lining up the washer with the fills, adjacent walls or cabinets.
You can level the washer using the adjustable leg spindle fitted to the cabinet.
Screw the ADJUSTABLE LEG SPINDLE legs up or down as required.
When washing machine does not even out, turn ADJUSTABLE LEG SPINDLE right or left to be level.
Location of drop
Cause How to adjust
Adjust the front adjusting plate with the adjustable
legs(2) or adjust the adjustable legs.
Adjust the rear adjusting plate with the adjustable
legs(2) or adjust the supporting plate.
Adjust the left part of the front and rear adjusting
plates or the supporting plate.
Adjust the right part of the front and rear adjusting
plates or the supporting plate.
When the front is lower.
When the rear is lower.
When the left is lower.
When the right is lower.

LG WT-R10(~3)3(7)1(3,5)TP(H) Specifications

General

Power Sourse	Refer to rating label on the back of Washer
Input	Refer to rating label on the back of Washer
Rating of Fuse	250V, 8A for 220~240V/50Hz 125V, 12A for100~127V/60Hz
Auto Power Off	Applied
Capacity	Refer to rating label on the back of Washer
Spin Speed	710 50
Lint Filter	Double
Softener Dispenser	Applied
Detergent Dispenser	Applied
Bleach Inlet	Applied
Inner Tub	Stainless
Inlet Water Pressure	0.3kgf/cm2~ 8kgf/cm2
Water Level	7 Stages
Reservation	Available for 3 ~ 24 Hr
Program	DELICATE, WOOL, NORMAL, SPEEDY, JEAN
Lid Interlock Switch	Magnet Sensor
Child Lock	Applied

Weight and Dimensions

Dim.	Refer to rating label on the back of Washer
Weight	Refer to rating label on the back of Washer
