LG WT-R10(~3)3(7)1(3,5)TP(H) User Manual

50
4) Water doesn’t come into the wash tub.
Where, what & how to check? Result of Check Possible Cause How to repair & settle
Inlet V
alve
1. If water doesn’t come though the
inlet valve works(electric sound
occurs)
1) Check whether water mains is cut.
2) Check whether tabs are turned on.
3) Hot & cold tab are opposite
connected.
4) Wrongly select water temperature
option.
5) If there are no problems in the
above, check the inlet valve filters
after disconnecting the water supply
hoses.
6) If there are no problems in the
above a diaphragm hole in the valve
is blocked by foreign substance or
the plunger in it is locked.
2. If the inlet valve doesn’t work(there
is no electric sound)during filling
cycle.
1) Check whether it’s connectors are
taken off or they have poor
connection.
2) Check resistance of the inlet valve.
Water mains cut.
Don’t tumed on.
Connected
opposite.
Selected
opposite.
Filters blocked
by foreign
substance.
A connector is
taken off.
Mains cut.
Mistake of use.
Wrong installation.
Mistake of use.
Don’t clean.
Defect of the
inlet valve.
Defect of contact.
Coil is open
Explain.
Turn on the tap.
Correct their locations
and turn on the tap.
Explain how to use.
Clean them by brush
and explain cleaning
regulary them.
Change the inlet valve.
Reconnect it or remove
the causes to make poor
connection.
Change the inlet valve.
3) Reset During operation
Where, what & how to check? Result of Check Possible Cause How to repair & settle
Controller
1. If mains voltage and the drain motor
have no defects a defect of the
controller is highly possible.
Change the controller.

LG WT-R10(~3)3(7)1(3,5)TP(H) Specifications

General

Power Sourse	Refer to rating label on the back of Washer
Input	Refer to rating label on the back of Washer
Rating of Fuse	250V, 8A for 220~240V/50Hz 125V, 12A for100~127V/60Hz
Auto Power Off	Applied
Capacity	Refer to rating label on the back of Washer
Spin Speed	710 50
Lint Filter	Double
Softener Dispenser	Applied
Detergent Dispenser	Applied
Bleach Inlet	Applied
Inner Tub	Stainless
Inlet Water Pressure	0.3kgf/cm2~ 8kgf/cm2
Water Level	7 Stages
Reservation	Available for 3 ~ 24 Hr
Program	DELICATE, WOOL, NORMAL, SPEEDY, JEAN
Lid Interlock Switch	Magnet Sensor
Child Lock	Applied

Weight and Dimensions

Dim.	Refer to rating label on the back of Washer
Weight	Refer to rating label on the back of Washer
