51
5) Water fills continuously or intermittently.
Where, what & how to check? Result of Check Possible Cause How to repair & settle
W
rong Installation/Leakage
1. Check whether the drain hose is
laying down on the floor.
(For pump model)
2. Check where water leaks.
Pressure Switch
1. Check the pulsator is rotating when
water fills continuously.
2. If there is no defect in the pressure
swith, check whether the air hole of
the outer tub is blocked.
Inlet Valve
1. Does water fills even though it is not
energized (power is off)?
Controller
1. Does water fill immediately after the
power switch turns on before pushing
the start/pause button.
Drain hose
laying down.
Water leaks
from a part.
It doesn’t
rotate.
Blocked.
Water fills.
Wrong installation.
Defect of the part.
Water pressure is
not sensed.
Air hole blocked.
Defect of the inlet
valve.
Short circuit of the
triac of the
controller.
The drain hose
should be hung on the
stand-pipe or the tub.
Change the part.
Repair it.
Check the tube of the
pressure swith,if it is bent
or blocked, repair that.
Repair the blocked hole.
Change the inlet valve.
Change the controller.
4) Water doesn’t come into the wash bowl.
Where, what & how to check? Result of Check Possible Cause How to repair & settle
Pressure Switch
1. Is there PE error on the display
which means pressure switch error
2. Check frequency of the pressure
switch without load if wash is
proceeding without filling.
Controller
1. Defect of controller is highly possible
if inlet valve and pressure switch have
no defects in the above.
Reconnect the connector
or change leads. Change
the pressure switch if coil
is open.
Change the pressure
switch.
Change the controller.
PE Error
displayed.
Less then
26.2
Connector is taken
off, or lead or coil is
open.
Defect of the
pressure switch.

LG WT-R10(~3)3(7)1(3,5)TP(H) Specifications

General

Power Sourse	Refer to rating label on the back of Washer
Input	Refer to rating label on the back of Washer
Rating of Fuse	250V, 8A for 220~240V/50Hz 125V, 12A for100~127V/60Hz
Auto Power Off	Applied
Capacity	Refer to rating label on the back of Washer
Spin Speed	710 50
Lint Filter	Double
Softener Dispenser	Applied
Detergent Dispenser	Applied
Bleach Inlet	Applied
Inner Tub	Stainless
Inlet Water Pressure	0.3kgf/cm2~ 8kgf/cm2
Water Level	7 Stages
Reservation	Available for 3 ~ 24 Hr
Program	DELICATE, WOOL, NORMAL, SPEEDY, JEAN
Lid Interlock Switch	Magnet Sensor
Child Lock	Applied

Weight and Dimensions

Dim.	Refer to rating label on the back of Washer
Weight	Refer to rating label on the back of Washer
