54
Where, what & how to check? Result of Check Possible Cause How to repair & settle
Drain Motor
(For Non-Pump Model only)
1. Check resistance of the drain
motor if it can not pull the PV link.
Resistance is
normal.
Drain motor coil is
open.
Contact defect in
connection parts
or defect of the
controller.
Change the drain motor
Check the washer
works normally after
reassembling.
(PV link & drain motor
lever should be
assembled accurately.)
Change the controller if
there is no defects in the
connection parts.
8) Water drains though it is not the time of drain.
Where, what & how to check? Result of Check Possible Cause How to repair & settle
Drain Motor
(for Non-Pump Model only)
1. Check whether the drain motor is
normally returned after turning
power off.
(It is considered normal if the lever
of the drain motor is fully pulled out
by the PV spring)
PV Case
1. If water drains though the drain
motor is normally returned, check
whether PV asm is blocked by
foreign objects or the bellows in
the PV asm is deformed.
Controller
1. Check whether the drain motor or
the drain pump works immediately
after power is turned on.
Blocked.
Blocked.
Bellows
deformed.
Works.
Defect of the drain
motor.
Defect of PV
Bellows.
Defect of the
controller(Triac
defect)
Drain Hose
1. Check whether the drain hose is
installed properly so that the
discharge hight is about
0.9~1.2m from the floor.
The discharge
height is lower
than
recommendation.
Wrong installation
of the drain hose.
Put the outlet of drain
hose between 0.9m and
1.2m
Change the drain motor.
Remove the objects in
the PV asm.
Change the PV bellows.
(The bellows may swell
up if it contact petroleum
or petrochemical
substance because it is
made of rubber)
Change the controller.

LG WT-R10(~3)3(7)1(3,5)TP(H) Specifications

General

Power Sourse	Refer to rating label on the back of Washer
Input	Refer to rating label on the back of Washer
Rating of Fuse	250V, 8A for 220~240V/50Hz 125V, 12A for100~127V/60Hz
Auto Power Off	Applied
Capacity	Refer to rating label on the back of Washer
Spin Speed	710 50
Lint Filter	Double
Softener Dispenser	Applied
Detergent Dispenser	Applied
Bleach Inlet	Applied
Inner Tub	Stainless
Inlet Water Pressure	0.3kgf/cm2~ 8kgf/cm2
Water Level	7 Stages
Reservation	Available for 3 ~ 24 Hr
Program	DELICATE, WOOL, NORMAL, SPEEDY, JEAN
Lid Interlock Switch	Magnet Sensor
Child Lock	Applied

Weight and Dimensions

Dim.	Refer to rating label on the back of Washer
Weight	Refer to rating label on the back of Washer
