6
2-2. CONNECTING WATER SUPPLY HOSE
Before connecting the Water Supply Hose to the water tap, check the hose type and then choose the
correct instruction here under.
Note that the Water Supply Hose supplied may vary from country to country, Make sure to connect the
blue inlet hose to the COLD water tap, and the orange inlet hose to the HOT water tap.
Connecting Water Supply Hose to water tap
Normal Type
(Normal tap without thread & screw type inlet hose.)
1
2
3
4
5
Untighten the screw
Untighten the screw of the connector so that the tap
can be placed in the middle.
Fixing the connector to the tap
Push the upper connector up till the rubber packing is in
tight contact with the tap. Then tighten the 4 screws.
Rubber packing
Attach the water supply hose securely to the
connector
Push the water supply hose vertically upwards
so that the rubber seal within the hose can
adhere completely to the tap.
Connector
Water supply hose
Fixing the connector to the water supply hose
Attach the water supply hose to the connector and
then tighten it by screwing it to the right.
Check the connection of water supply hose and the connector
After connecting the hose, open the tap to check for any water
leakage.
If the water leaks, close the tap and start again from step 1.
The washing machine is to be connected to the water mains using new hose-sets and old hose-sets should
not be reused.
Note
