8 PRODUCT OVERVIEW
Accessories
Included Accessories
a Tie Strap
b Leg Holders
†
† Use leg holders for models WT7800C*, WT7880H*A, and WT7900H*A only. Refer to the installation
guide included with the leg holders.
Required Accessories (sold separately)
a Hot and Cold Water Hoses
Product Specifications
The appearance and specifications listed in this manual may vary due to constant product improvements.
Model
WT7060C* / WT7100C*
/ WT7300C* /
WT7250C* / WT7305C*
WT7800C* /
WT7880H*A /
WT7900H*A /
WT7400C* / WT7405C*
WT7005C* / WT7150C*
/ WT7155C*
Electrical Requirements 120 V~, 60 Hz
Min. / Max. Water
Pressure
20 psi - 120 psi (138 kPa - 827 kPa)
Dimensions (Width X
Depth X Height)
27" X 28 3/8" X 44 1/2" (68.6 cm X 72.1 cm X 113 cm)
Maximum Depth with
Lid Open
57 1/4” (145.3 cm)
Net Weight 127.9 lbs (58 kg) 132.3 lb (60 kg) 127.9 lbs (58 kg)
Maximum Spin Speed 950 RPM (±50 rpm) 800 RPM (±50 rpm)
us_main.book.book Page 8 Thursday, November 4, 2021 11:22 AM
