Initial Set Up

Step 1

When ordering an EHC Radio Frequency (R/F) controlled radiator, the radiator will already

have the receiver wired in to it (as illustrated on previous page).

Step 2

Once connected, the receiver will show a yellow LED light indicating that it is manual mode

Step 3

Push the button on the receiver for 5 seconds until the green light appears, indicating that the

receiver is ready to be linked to the thermostat.
