Lian-Li PC-O11 Dynamic EVO Svart User Manual

- 7 -
PSU Installation
電源供應器安裝/ Installation du plateau du bloc d'alimentation / PSU-Einsatz installieren /
Instalación de la fuente de alimentación / 電源のインストール
注意
先選擇PSU安裝位置(下或上)
Select the PSU position
(LOWER or UPPER).
2.5" SSD 安裝 /
 
/ Installation de 2.5" SSD
2.5" SSD-Installation / Instalación de 2.5" SSD /

2.5" SSD

の取り付け
2.5" SSD Installation
撕開背膠
Peal the
layer on adhesive
2
1
2
LOWER
r
撕開背膠
Peal the
layer on adhesive
。
3
1
1
此線材遮板可反向裝置。
Cable mangement bar
can be inverted.
注意
2

Lian-Li PC-O11 Dynamic EVO Svart Specifications

General

Type	Mid Tower
Expansion Slots	8
Color	Black
Dust Filters	Bottom, Side, Top
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Material	Steel, Tempered Glass, Aluminum
Front I/O Ports	1 x USB 3.1 Type-C, 2 x USB 3.0, 1 x Audio
Radiator Support	Top: 360mm, Bottom: 360mm, Side: 360mm
GPU Length Clearance	420mm
CPU Cooler Height Clearance	167mm
PSU Length Clearance	220mm (Max.)
Drive Bays	2 x 2.5", 2 x 3.5"
