6 | EN Copyright © Liberty Pumps, Inc. 2019
All rights reserved. 8338000E
Panel Indicators
The horn and LEDs are used to show various conditions in the
controller. Each indicator is described in Table 3. Note that on
backup power, no LEDs will be illuminated steady.
Operator Controls
The operator has access to controls to silence the horn alarm, test
the alarm circuits, and reset the panel.
Warranty
Liberty Pumps Wholesale Products Limited
Warranty
Liberty Pumps, Inc. warrants that Liberty Pumps wholesale
products are free from all factory defects in material and
workmanship for a period of three (3) years from the date of
purchase (excluding batteries). The date of purchase shall be
determined by a dated sales receipt noting the model and serial
number of the pump. The dated sales receipt must accompany the
returned pump if the date of return is more than three years from
the date of manufacture noted on the pump nameplate.
The manufacturer's sole obligation under this Warranty shall be
limited to the repair or replacement of any parts found by the
manufacturer to be defective, provided the part or assembly is
returned freight prepaid to the manufacturer or its authorized
service center, and provided that none of the following
warranty-voiding characteristics are evident:
The manufacturer shall not be liable under this Warranty if the
product has not been properly installed, operated, or maintained
per manufacturer instructions; if it has been disassembled,
modified, abused, or tampered with; if the electrical cord has been
cut, damaged, or spliced; if the pump discharge has been reduced
in size; if the pump has been used in water temperatures above
the advertised rating; if the pump has been used in water
containing sand, lime, cement, gravel, or other abrasives; if the
product has been used to pump chemicals, grease, or
hydrocarbons; if a non-submersible motor has been subjected to
moisture; or if the label bearing the model and serial number has
been removed.
Liberty Pumps, Inc. shall not be liable for any loss, damage, or
expenses resulting from installation or use of its products, or for
indirect, incidental, and consequential damages, including costs of
removal, reinstallation or transportation.
There is no other express warranty. All implied warranties,
including those of merchantability and fitness for a particular
purpose, are limited to three years from the date of purchase.
This Warranty contains the exclusive remedy of the purchaser,
and, where permitted, liability for consequential or incidental
damages under any and all warranties are excluded.
Table 3. Backup Power Indications
Indicator State Description
High Water
Alarm LED
OFF There is no alarm condition.
Flashing An alarm condition is active.
Horn
Disabled LED
(indoor
models)
OFF
Horn operation is Enabled. The
horn will
beep in an alarm
condition.
Flashing Horn operation is Disabled.
Pump 1 Run
LED
OFF
The Pump 1 indicator will always be
OFF when on alarm backup power.
Pump 2 Run
LED
OFF
The Pump 2 indicator will always be
OFF when on alarm backup power.
Power LED
OFF
Power is off to the panel and the
backup alarm battery is dead.
Flashing
Primary power to the panel is Off;
the panel is on alarm backup
power. Pumps will not
run.
Alarm Horn
OFF No alarm condition is present.
Beeping An alarm condition is present.
Table 4. Backup Power Operator Controls
Control
Pushbutton
Existing
Condition
Action When Pressed
Alarm Test —
Horn, alarm indicator, and auxiliary
relay will turn on. They will remain
in that state until the button is
released.
Horn Silence
(indoor
models)
Horn
Disabled
indicator
is flashing
Horn Disabled indicator will stop
flashing and the horn will be
enabled.
Horn
Disabled
indicator
is OFF
Horn Disabled LED will start
flashing and the horn will be
disabled for 12 hours. After 12
hours, the indicator will turn off
automatically and the horn will
then be enabled.
Pump Run — Not available on battery power.
Test - Reset —
Resets the system; all LEDs will stop
flashing.
Alarm Silence
Switch on
unit exterior
(outdoor
models)
Alarm is
sounding
Alarm is silenced.
©2019 SJE, Inc. All Rights Reserved.
SJE RHOMBUS is a trademark of SJE, INC.
PN 1038601B • Rev 11/19
