Liebert 700 VA - User Manual

Questions and Answers

C
Christopher JohnsAug 14, 2025
Why does my Liebert UPS have reduced battery time?
- J
  Jeffery Howell Jr.Aug 15, 2025
  Reduced battery time on your Liebert UPS can occur if the batteries are not fully charged. To resolve this, keep the UPS plugged in continuously for at least 24 hours to recharge the batteries. Another reason might be that the UPS is overloaded. Check the load level display and remove any non-essential loads. Finally, the batteries may be old and unable to hold a full charge, in which case you should replace them.
C
Chris CantuAug 18, 2025
Why is the utility indicator flashing on my Liebert 700 VA?
- L
  lmartinezAug 18, 2025
  A flashing utility indicator on your Liebert UPS means it is operating in battery mode. This could be because the UPS is not securely plugged into the wall receptacle, so ensure it is properly connected. It could also mean that the UPS input protection has opened. If this is the case, save your data, close applications, replace the UPS input fuse or reset the input breaker, and then restart the UPS. The utility voltage may also be out of the UPS input range, so save your data and close applications, and ensure that the utility supply voltage is within acceptable limits for the UPS.
D
Darryl CarterAug 21, 2025
What to do if Liebert 700 VA UPS fails to start?
- A
  Alexandria MorrisonAug 21, 2025
  If your Liebert UPS fails to start when the On/Off button is pressed, it could be due to a short circuit or overload on the UPS output. Turn off the UPS, disconnect all loads, and make sure nothing is lodged in the output receptacles. Also, ensure that the connected loads are not defective or shorted internally. Another possibility is that the internal fuse has blown, indicating an internal fault.
C
cleAug 25, 2025
How to fix Liebert 700 VA UPS shutting down with fault A and D LEDs on?
- J
  Jennifer RomeroAug 25, 2025
  If your Liebert UPS shuts down and the “Fault” indicator and diagnostic LEDs “A” & “D” are illuminated, it indicates an internal over temperature condition. Make sure the UPS is not overloaded, that the ventilation openings are not blocked, and that the room ambient temperature is not excessive. Wait 30 minutes to allow the UPS to cool down, then restart it.
A
Adam RodriguezAug 28, 2025
What to do if Liebert UPS shuts down with fault D LED on?
- S
  Scott WilsonAug 28, 2025
  If your Liebert UPS shuts down and the “Fault” indicator and diagnostic LED “D” is illuminated, it means the UPS is overloaded or the connected equipment is faulty. Check the load level display and remove any non-essential loads. Recalculate the load VA and reduce the number of loads connected to the UPS. Also, check the connected equipment for faults.
R
Ronald AndersonAug 31, 2025
Why Liebert 700 VA shuts down with fault B and D LEDs illuminated?
- K
  Kristin LutzAug 31, 2025
  If your Liebert UPS shuts down and the “Fault” indicator and diagnostic LEDs “B” & “D” are illuminated, it means the UPS has shut down due to a command from the communications port(s). Your UPS has received a signal or command from the attached computer. If this was inadvertent, ensure the communication cable used is correct for your system.
J
jjohnsonSep 4, 2025
What does it mean when fault indicator and LED B are illuminated on Liebert 700 VA?
- C
  Catherine EvansSep 4, 2025
  If the “Fault” indicator and diagnostic LED “B” are illuminated on your Liebert UPS, it means the UPS failed the battery test.
B
Brian SerranoSep 6, 2025
What does fault indicator A mean on Liebert UPS?
- M
  Michael JonesSep 7, 2025
  If the “Fault” indicator and diagnostic LED “A” are illuminated on your Liebert UPS, it indicates a UPS fan failure or battery overcharge.
L
Linda WhiteSep 12, 2025
What does it mean when Liebert UPS shuts down and fault A and B LEDs are on?
- C
  Casey WolfeSep 12, 2025
  If your Liebert UPS shuts down and the “Fault” indicator and diagnostic LEDs “A” & “B” are illuminated, it means the UPS shutdown due to internal failure.

Summary

POWER PROTECTION

IMPORTANT SAFETY INSTRUCTIONS

INTRODUCTION & SYSTEM DESCRIPTION

MAJOR COMPONENTS

TRANSIENT VOLTAGE SURGE SUPPRESSION (TVSS) AND EMI;RFI FILTERS

Components that protect against surges and interference.

AUTOMATIC VOLTAGE REGULATOR

Regulates output voltage during utility fluctuations.

BI-DIRECTIONAL CONVERTER

Converts AC to DC for charging and DC to AC for output.

BATTERY

Details on the valve-regulated, nonspillable lead-acid batteries.

MINI-TOWER INSTALLATION

RACKMOUNT INSTALLATION

CONTROLS AND INDICATORS

On;Off Button

Functionality of the UPS power on/off control button.

Load;Battery Level Indicators

LED indicators for load percentage and battery capacity.

Status Indicators

LEDs for utility status, fault, and wiring errors.

Alarm Silence;Battery Test Button

Button for silencing alarms and testing battery performance.

POWERSURE INTERACTIVE MINI-TOWER

POWERSURE INTERACTIVE RACKMOUNT

OPERATION

NORMAL MODE OPERATION

How the UPS functions during normal utility power.

UTILITY HIGH;LOW MODE OPERATION

UPS response to high or low utility voltage conditions.

COMMUNICATIONS INTERFACE PORT

UPS MONITORING

Capability and use of the DB-9 port for monitoring UPS status.

UPS INTELLIGENT COMMUNICATIONS

UPS INTELLISLOT COMMUNICATIONS

MAINTENANCE

MINI-TOWER BATTERY REPLACEMENT

RACKMOUNT BATTERY REPLACEMENT

TROUBLESHOOTING

TROUBLESHOOTING GUIDE

TYPICAL BATTERY DISCHARGE CURVES

AUDIBLE ALARM CONDITIONS

FUSE REPLACEMENT PROCEDURES FOR 700 VA MODELS

MINI-TOWER SPECIFICATIONS

RACKMOUNT SPECIFICATIONS

Technical Support

Liebert 700 VA Specifications

General

Output Power	420 W
Form Factor	Tower
Frequency	50/60 Hz
Capacity	700 VA
Input Voltage	230V
Output Voltage	230V
Battery Type	Sealed Lead-Acid (SLA)
Output Connections	IEC 320 C13
