RACKMOUNT SPECIFICATIONS
Model Number
PS700RM-120 PS1000RM-120 PS1400RM-120 PS2200RM-120
Model Rating VA/W 700 / 450 1000 / 670 1400 / 950 2200 / 1600
DIMENSIONS: in (mm)
Unit
W x D x H
19 x 18 x 5.25
(483 x 457 x 133)
19 x 18 x 5.25
(483 x 457 x 133)
19 x 18 x 5.25
(483 x 457 x 133)
19 x 18 x 7
(483 x 457 x 178)
Shipping
W x D x H
27.5 x 24 x 11
(699 x 610 x 279)
27.5 x 24 x 11
(699 x 610 x 279)
27.5 x 24 x 11
(699 x 610 x 279)
27.5 x 24 x 12
(699 x 610 x 305)
WEIGHT: lbs (kg)
Unit 41.5 (18.9) 51.29 (23.3) 57.2 (26.0) 86.0 (39.1)
Shipping 50.82 (23.1) 59.85 (27.2) 66.1 (30.0) 95.3 (43.3)
INPUT AC PARAMETERS
Voltage Range 120 VAC; -25%, +23%
Voltage Raise Maintains output to 120 VAC; -14%, when input is 120 VAC, -25%
Voltage Lower Maintains output to 120 VAC; +10%, when input is 120 VAC, +23%
Frequency 45-55 Hz or 55-65 Hz; auto sensing
Input
Power Cord
6 ft. detachable, w/
NEMA 5-15 P
6 ft. attached, w/
NEMA 5-15 P
6 ft. attached, w/
NEMA 5-15 P
6 ft. attached, w/
NEMA L5-30 P
OUTPUT AC PARAMETERS
Output Receptacles (6) 5-15R (6) 5-15R (6) 5-15R
(6)5-15R (2)5-20R
Voltage 103 VAC to 132 VAC
Max. Current Rating 5.8 A 8.3 A 11.67 A 18.3 A
Frequency 50 Hz or 60 Hz
Waveform Sinewave
Utility Mode Overload 200% for > 2 cycles; 110% for > 5 minutes
Battery Mode Overload 150% for > 1 cycle; 110% for > 30 seconds
BATTERY PARAMETERS
Type Valve-regulated, nonspillable, lead acid
Qty. x Voltage x Rating
2 x 12V x 7.0 or 7.2 AH 3 x 12V x 7.0 or 7.2 AH 4 x 12V x 7.0 or 7.2 AH 8 x 6V x 12 AH
Batt. Mfg./ Part Number CSB: GP1270F2 or Panasonic LC-R127R2CH1
Panasonic:
LC-R0612CH1
Transfer Time 2-6 ms typical
Back-up Time See Typical Battery Discharge Curves
3 Hours 3 Hours 5 Hours 3 HoursRecharge Time
to 95% capacity, after full discharge into 100% load
ENVIRONMENTAL
Operating Temperature +32° F to + 104° F (0° C to +40° C)
Storage Temperature +5° F to + 122° F (-15° C to +50° C)
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 10,000 ft. (3000 m) at 35° C without derating
Storage Elevation 50,000 ft. (15,000 m) maximum
Audible Noise <45 dBA, at 1 meter
AGENCY
Safety UL 1778, c-UL Listed
RFI/EMI FCC Part 15, Subpart B, Class A
Immunity IEC 801-2, Level 4 / IEC 801-4, Level 4 / IEEE 587 Category A
DISCONTINUED
PRODUC T
