Liebert TCDVTM User Manual

Introduction
3
Table 3 Condenser performance, 60Hz
Model
Number
Total Heat Rejection BTU/Hr (kW) Based on TD
CFM
(CMH)
Sound
dBA
Fan
Qty
30°F TD
(16.7°C)
25°F TD
(13.9°C)
20°F TD
(11.1°C)
15°F TD
(8.3C)
1°F TD
(0.6°C)
R-22 Refrigerant
TCDV165
178,410
(52.2)
148,675
(43.5)
118,940
(34.8)
89,205
(26.1)
5,947
(3.1)
13,300
(22,597)
75.5 2
TCDV205
264,930
(77.6)
220,775
(64.6)
176,620
(51.7)
132,465
(38.8)
8,831
(4.7)
11,200
(19,029)
TCDV251
298,170
(87.3)
248,475
(72.8)
198,780
(58.2)
149,085
(43.7)
9,939
(5.2)
20,250
(34,405)
77.3 3
TCDV308
384,180
(112.5)
320,150
(93.7)
256,120
(75.0)
192,090
(56.2)
12,806
(6.7)
18,600
(31,602)
TCDV415
507,690
(148.7)
423,075
(123.9)
338,460
(99.1)
253,845
(74.3)
16,923
(8.9)
24,800
(42,135)
78.5 4
TCDV510
552,240
(161.7)
460,200
(134.8)
368,160
(107.8)
276,120
(80.9)
18,408
(9.7)
19,200
(32,621)
R-407C Refrigerant
TCDV165
143,160
(41.9)
119,300
(34.9)
95,440
(27.9)
71,580
(21.0)
4772
(2.5)
13,300
(22,597)
75.5 2
TCDV205
242,100
(70.9)
201,750
(59.1)
161,400
(47.3)
121,050
(35.4)
8070
(4.3)
11,200
(19,029)
TCDV251
277,380
(81.2)
231,150
(67.7)
184,920
(54.1)
138,690
(40.6)
9246
(4.9)
20,250
(34,405)
77.3 3
TCDV308
337,890
(98.9)
281,575
(82.4)
225,260
(66.0)
168,945
(49.5)
11263
(5.9)
18,600
(31,602)
TCDV415
472,320
(138.3)
393,600
(115.3)
314,880
(92.2)
236,160
(69.2)
15744
(8.3)
24,800
(42,135)
78.5 4
TCDV510
452,820
(132.6)
377,350
(110.5)
301,880
(88.4)
226,410
(66.3)
15094
(8.0)
19,200
(32,621)
TD = Difference between Entering Air Temperature and Condensing Temperature
