Table 4 Condenser performance, 50Hz
Model
Number
Total Heat Rejection BTU/hr (kW) based on TD
CFM
(CMH)
Sound
dBA
Fan
Qty
30°F TD
(16.7°C)
25°F TD
(13.9°C)
20°F TD
(11.1°C)
15°F TD
(8.3°C)
1°F TD
(0.6°C)
R-22 Refrigerant
TCDV165
162,660
(47.6)
135,550
(39.7)
108,440
(31.8)
81,330
(23.8)
5,422
(2.9)
11,100
(18,859)
71.0 2
TCDV205
233,040
(68.2)
194,200
(56.9)
155,360
(45.5)
116,520
(34.1)
7,768
(4.1)
9,300
(15,801)
TCDV251
270,150
(79.1)
225,125
(65.9)
180,100
(52.7)
135,075
(39.6)
9,005
(4.7)
16,800
(28,543)
72.8 3
TCDV308
343,080
(100.5)
285,900
(83.7)
228,720
(67.0)
171,540
(50.2)
11,436
(6.0)
15,450
(26,250)
TCDV415
454,680
(133.1)
378,900
(110.9)
303,120
(88.8)
227,340
(66.6)
15,156
(8.0)
20,600
(35,000)
74.0 4
TCDV510
479,040
(140.3)
399,200
(116.9)
319,360
(93.5)
239,520
(70.1)
15,968
(8.4)
16,000
(27,184)
R-407C Refrigerant
TCDV165
129,960
(38.1)
108,300
(31.7)
86640
(25.4)
64,980
(19.0)
4,332
(2.3)
11,100
(18,859)
71.0 2
TCDV205
212,280
(62.2)
176,900
(51.8)
141520
(41.4)
106,140
(31.1)
7,076
(3.7)
9,300
(15,801)
TCDV251
250,920
(73.5)
209,100
(61.2)
167280
(49.0)
125,460
(36.7)
8,364
(4.4)
16,800
(28,543)
72.8 3
TCDV308
301,950
(88.4)
251,625
(73.7)
201300
(58.9)
150,975
(44.2)
10,065
(5.3)
15,450
(26,250)
TCDV415
422,400
(123.7)
352,000
(103.1)
281600
(82.5)
211,200
(61.8)
14,080
(7.4)
20,600
(35,000)
74.0 4
TCDV510
391,800
(114.7)
326,500
(95.6)
261200
(76.5)
195,900
(57.4)
13,060
(6.9)
16,000
(27,184)
TD = Difference between Entering Air Temperature and Condensing Temperature
