FlexPower Vantage Standard Power System - Installation Manual 8
FPV4 / FPV6 Electrical / Mechanical Specifications
FPV4 FPV6
AC Input Voltage 120VAC or 230VA at 50-60Hz 120VAC or 230VAC at 50-60Hz
Current 1.8A maximum 3.7A maximum
Standby Current 80mA 150mA
DC Output at 12V Setting
(Auxiliary power-limited output
rated at 1.5A. Total current must
not exceed max current)
Voltage 11.3 - 12.0V 11.2 - 12.0V
Max Current 4A 6A
Ripple & Noise 120mV 120mV
Regulation ±2% ±2%
Efficiency 82% (120VAC
60Hz In, Full Load, No Batt)
88% (120VAC
60Hz In, Full Load, No Batt)
Auxiliary Output (12V) Current 1.5 A max 1.5 A max
DC Output at 24V Setting
(Auxiliary power-limited output
rated at 1.5A. Total current must
not exceed max current)
Voltage 23.5 - 24.0 23.2 - 24.0
Max Current 3A 6A
Ripple & Noise 240mV 240mV
Regulation ±2% ±2%
Efficiency 83% (120VAC 60Hz Input,
Full Load No Batt)
85% (120VAC 60Hz Input,
Full Load No Batt)
Auxiliary Output (24V) Current 1.5 A max 1.5 A max
Battery Size & Type 4-40AH Lead Acid
or Gel Cell
4-80AH Lead Acid
or Gel Cell
Charge Current 1A (±10%) maximum
adjustable via DIP switch. 1.0A
high setting, 0.5A low setting.
1.6A (±10%) maximum
adjustable via DIP switch. 1.6A
high setting, 0.8A low setting.
Low battery disconnect to
prevent deep discharge
70% of nominal
battery voltage
70% of nominal
battery voltage
Fuse Rating Battery ATM 15A ATM 15A
BTU Output BTU/Hr 34-41 44-62
Fault Setpoints Low AC 95V (±6%) 95V (±6%)
Output Voltage ±10% of nominal ±10% of Nominal
Fault Relay Contacts AC FLT 1A at 24VDC 1A at 24VDC
SYS FLT 1A at 24VDC 1A at 24VDC
Operating Temperature 0 – 49C° 0 – 49C°
Board Size / Weight 6.0L x 4.0W x 2.50"H | 1.0 lbs 8.25L x 5.50W x 2.50"H |1.0 lbs
Enclosure Size / Weight 14H x 12W x 4.5"D | 14 lbs 14H x 12W x 4.5"D | 14 lbs
