AM-HLTMC-OM
Rev AA January 2018
INSTALLATION
WARNING: The shipping pallet must be removed for proper and safe operation.
Location
For maximum trouble-free service, choose a location which is free of excess moisture, dust, and
corrosive fumes. Also, avoid locations where temperatures are high or where liquids will drip on
the charger. Do not obstruct the ventilating openings or the space under the charger.
Mounting Wall Cabinet Chargers
The charger must be mounted on a wall or stand in a vertical position. The lower part of the
charger must be at least 24” from the ground and/or the charger below and the upper part 36”
from the ceiling. The minimum distance between two chargers must be 12”.
The charger will be installed with the brackets supplied. See the Wall Mounting Dimensions
section at the end of this manual for proper bolt pattern.
NOTE: Ambient temperature at all levels cannot exceed 113
O
F / 45
O
C.
Electrical Connections
To prevent failure of the charger, be sure it is connected to the correct line voltage.
Connecting Input Power
WARNING: Make sure the power to the charger is OFF and the battery is disconnected before
connecting the input power to the terminals of the charger.
Connect the input power to the appropriate terminals, including ground. Follow your local
electrical or National Electric Code in making these connections.
AC Connection
The user must provide suitable branch circuit protection and a disconnect method from the AC
power supply to the charger to allow for safe servicing.
Plug Polarity
The charging cable is connected to the DC output of the charger with the RED lead to positive
and BLACK to negative. The output polarity of the charger must be strictly observed when
connecting to the battery (read warning above). Improper connection will open the DC fuse.
Grounding the Charger
DANGER: FAILURE TO GROUND THE CHARGER COULD LEAD TO FATAL ELECTRIC
SHOCK. Follow National Electric Code for ground wire sizing.
Connect a grounding conductor to the terminal block provided on the horizontal support panel.
Marked as shown:
