Lifetime 12347 - Assembly Instructions; Tube Assembly

6
Required For This Page:
1. Insert Swaged Tube (AA) into Tube (AB).
4. Place Tube Assembly between flaps of Net (AC) and align the six holes in the Tube
Assembly with the six holes in the Net flaps.
*AA
*AB
2. Secure the Tube Assembly together using one (1) 6 mm Screw (NE).
3. Insert a 1” Plug (NF) into each end of the Tube Assembly.
(2)
1029637
Screwdriver
AA
AB
NE
NF
NF
NF
NE
