7/16” Wrenches
1029637
Required For This Page:
NA
NB
NC
5. Secure the Tube Assembly to the Net using one (1) 1/4”-20 x 1 3/4” Hex Bolt (NB),
two (2) 1/4” Flat Washers (NC), and one (1) 1/4”-20 Cap Nut (NA) for each hole.
(6)
(6)
(12)
NA NC
NC
NB
WARNING
Do not overtighten the Cap Nut. If the end of
the Bolt breaks through the plastic cap, call our
Customer Service Department at the number
on Page Two. Exposed threads on the end of
the Bolt may cause serious injuries.
To Next Page
