Lifetime 12347 - Harness Installation

8
*ND
1029637
Required For This Page:
6. Insert the straps of the Harness (ND) under and around the Tube Assembly as
shown.
7. Pull the straps of the Harness up through both the first and second rings.
Finally, loop the strap around Ring 2 and back through Ring 1 (as shown below).
Repeat for second strap.
ND
8. Pull down on the straps about six inches.
Ring 2
Ring 1
ND
Ring 2
