Lifetime 125 - TRUSS ASSEMBLY

20 1/8”
71 11/16”
79 1/2”
79 1/2”
7/16” WrenchY
TRUSS ASSEMBLY
HARDWARE REQUIRED
HARDWARE BAG REQUIRED: BGV
METAL PARTS REQUIRED
TOOLS REQUIRED
SEC
Safety Glasses
AFPY
Truss Support Strip
AIP (x1)
5SVTT(VUUFS$POOFDUPS
AHTY
Floor Bracket
AFHY
5SVTT(VUUFS$IBOOFM
AFG (x1)
Truss Brace Channel
AFQY
Wall/Shelf Support Channel
AAK (x10)
wYw)FY#PMU
ADJ (x10)
1/4” Cap Nut
Parts shown at 8% of actual size
Hardware shown at actual size
Hardware shown at 50% of actual size
4
