Lifetime 125 - Page 19

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
AFQ
AAK
ADJ
AFH
AFQ
AAKY
ADJY
SEC
Attach Truss Assembly to two Wall Support Channels (AFQ) using 1/4” x 1 1/2” Hex Bolts (AAK) and 1/4” Cap Nuts (ADJ).
Do not completely tighten the Cap Nut until after Truss is secured to the Wall.
Note: Only fi nger tighten hardware.
!
WARNING
Do not overtighten the Cap Nut.
7/16”Y
4.3
4.4
4
