Lifetime 2871 User Manual

7
BENCH FRAME ASSEMBLY
HARDWARE USED
METAL PARTS USED
PLASTIC PARTS USED
TOOLS USED (NOT INCLUDED)
SEC
1
PartsShownatSameScale
NO PLASTIC PARTS REQUIRED FOR THIS SECTION
BAM(x4)
1/4”NylockCapNut
BAN(x14)
M5x.8mmNylockNut
BCE(x8)
M5x.8mmx25mmPan-HeadScrew
Phillips Screwdriver
5/16” Wrench 7/16” Wrench
Safety Glasses
BAX(x1)
LeftArmWeldment
BAZ(x1)
SeatCrossSupport
BAV(x4)
BearingArm
BAW(x1)
RightArmWeldment
BAT(x1)
LeftLegAssembly
BAS(x1)
RightLegAssembly
BCF(x2)
M5x.8mmx33mmPan-HeadScrew
BAY(x1)
BackCrossSupport
BAU(x2)
LegCrossSupport
BCG(x4)
M5x.8x57mmPan-HeadScrew
