TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
9
SEC
1
BCG
BCG
BCG
BCG
BAN
BAN
BAN
BAZ
SEC
1.4
ConnecttheSeat Cross Support (BAZ)totheRight and Left Arms (BAW and BAX)usingthehardwareshown.
BCG(x4)
BAN(x4)
5/16”
BAX
BAW
1.
