Lifetime 60030 - Step 1.3: Insert Leg Assemblies; Step 1.4: Position Second Table Top Channel

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
7
SEC
SEC
1.3
SEC
1.3
1
2 ADULTS REQUIRED FOR THIS STEP
Insert a W-Frame Leg Assembly (BWO) and a W-Frame Leg Brace Assembly (BWP) into the two large holes along the Table
Top channel that is still connected to the Table Top as shown. Ensure you orient the Brace in the direction shown
(the locking mechanism must be visible). Repeat step 1.2 - 1.3 for the second W-Frame Leg Assembly and W-Frame Leg Brace
Assembly.
While another adult helps to hold the Assemblies in position, place the holes in the second Table Top channel
over the tubes of the Table Legs and Table Leg Braces as shown.
NO HARDWARE REQUIRED FOR THIS PAGE
SEC
1.3
SEC
1.4
BWO
Table Top Channel
Table Top Channel
