25
TOOLS AND HARDWARE REQUIRED
X SECTION 5 (CONTINUED)
• Flush with the Right Door
• Using an 1/8" (6,4 mm) Drill Bit (ARA), drill through the Door and into the Square Tube. Do not drill all the way through
the Door—just into the Tube.
• Insert an End Cap (BBH) into the end of the Square Tube (CHI). Gently, fi nish inserting the Tube until it’s fl ush with the bottom of
the Door.
5.3
5.4
!
BBH
BBH (x1)
ARA (x1)
To Next Page
