38
TOOLS AND HARDWARE REQUIRED
X SECTION 7 (CONTINUED)
ADZ (x15)
AHD
AHH
AGL
x5
Click!
• Attach this Corner Panel in the same manner you did the previous Corner Panel.
• Insert the tabs of two (2) Wall Panels (AHH & AHD) into the
slots along the left edge of the Floor. Slide the Panels
toward the Corner Panel. Secure the Panels to one another
using fi ve (5) Screws (ADZ) for each Panel.
7.9
(EUF)
EUF
7.10
To Next Page
