56
TOOLS AND HARDWARE REQUIRED
X SECTION 10 (CONTINUED)
10.2
ADZ (x3)
ADZ
BYT (x3)
BYT
• Orient the three top-most Clips (BYT) as shown in this image, and, using a pair of pliers, insert them in the locations indicated.
10.3
• Set a Truss Assembly into the notches on the fi rst two opposite Wall Panels. Set a Roof Panel onto the Gable, Wall
Panel, and Truss Assembly.
AGQ
• See Step 10.4.
!
To Next Page
