Lifetime 60231 - Page 7

7
X SECTION 1 (CONTINUED)
x8
1
!
TOOLS, PARTS, AND HARDWARE REQUIRED
• To ensure studs are in the correct location for nailing plywood in the next step, start measuring from the corner 16"
(40,1 cm), and then measure from center to center.
WOOD PLATFORM
1.2.1
1.2.2
x20
Start Here
2" x 4" x 81 1/2" (5,1 cm x 10,2 cm x 2,12 m) (x2)
2" x 4" x 80 3/8" (5,1 cm x 10,2 cm x 2,04 m) (x7)
16d 3" (16d x 7,62 cm) (x28)
81 1/2" (2,07 m)
83 3/8" (2,12 m)
80 3/8" (2,04 m)
• Ensure all lumber is treated and approved for outdoor use. Build frame to 81 1/2" x 83 3/8" (2,07 m x 2,12 m)
(outside dimensions). You can also use the plywood as a fl at surface when building this frame.
16" (40,1 cm)
16" (40,1 cm)
16" (40,1 cm)
16" (40,1 cm)
16" (40,1
cm)
81 1/2" (2,07 m)
83 3/8" (2,12 m)
80 3/8" (2,04 m)
