Lifetime 6417 - Page 36

36
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
ADZY
SEC
Align the holes in a Corner Channel (AFR) with the holes in two corner Wall Panels and secure the Corner Channel
UPUIF8BMM1BOFMTXJUIUXFMWF1/4” x 5/8” Phillips Pan-Head Screws (ADZ).
AHD
SEC
Install next Wall Panel (AHD) at the right, rear corner of the Shed.
77 1/2”
AFR (x1)
4
4.4
4.3
